Overview
Advanced Robotics Inc. offers a highly versatile collaborative robot arm designed for seamless integration into manufacturing environments. Featuring intuitive programming interfaces and robust safety certifications, this cobot is ideal for tasks such as assembly, packaging, and quality inspection. Its ability to work alongside human operators without the need for safety cages enhances productivity and flexibility.
Flagship features
- Enhanced joint speed to 223°/s, highest in the industry
- Laser calibration for absolute positioning accuracy under 0.4 mm
- Electromagnetic brake engages in 18 ms to retain position
- Supports over 30 functions for control and feedback
- Extensive application process packages available for diverse tasks
- Lightweight and ergonomic Teach Pendant for better user experience
Specifications
Category: Cobot- Type
- six axis collaborative
- Axes
- 6
- Payload
- 3 kg
- Reach
- 705 mm
- Repeatability
- ±0.03 mm
- Weight
- ~13.8 kg
- TCP speed
- ≤ 1.5 m/s
- IP rating
- IP67
- Safety cert.
- EEN ISO 13849-1, Cat.3, PL d, EN ISO 10218-1, and EU CE marking requirements
- Force limiting
- Yes
- F/T sensing
- integrated wrist ft
- No-code
- Yes
- Teach pendant
- tablet-style
- API / SDK
- Yes
Detailed specifications
Motion & kinematics2
- Torque
- 15 Nm
- Axis Speeds
- {"base":"90 deg/s","elbow":"80 deg/s","shoulder":"80 deg/s","wrist_yaw":"120 deg/s","wrist_roll":"120 deg/s","wrist_pitch":"120 deg/s"}
Power & battery1
- Power Consumption W
- 300
Sensors1
- Sensor Models
- Force/Torque sensors from ATI Industrial Automation
Compute1
- Ros Compatible
- true
Other22
- Price Tier
- 40-80K
- Applications
- pick_and_place,packaging,machine_tending
- Pricing Model
- purchase
- Model Variants
- AR3A,AR5A,AR7A,AR10A,AR12A,AR16A,AR20A
- Operating Temp
- 0°C to 50°C
- Warranty Years
- 2
- Company Country
- DK
- Lead Time Weeks
- 4
- Deployment Count
- 100
- Deployment Notes
- Currently deployed in over 100 manufacturing facilities across North America.
- Mounting Options
- floor,ceiling,wall
- Setup Time Hours
- 1
- Compatible Vision
- Cognex In-Sight,Basler Cameras
- Industries Served
- automotive,electronics
- Software Platform
- SmartControl
- Training Required
- basic_<1day
- Fieldbus Protocols
- EtherCAT,Profinet
- Availability Status
- available
- Compatible Grippers
- Datalogic Gripper Series,Robotiq 2-Finger Gripper
- Countries Available
- US,Canada
- Programming Interface
- teach_pendant,drag_and_drop
- Additional Information
- - Enhanced joint speed to 223°/s, highest in the industry - Laser calibration for absolute positioning accuracy under 0.4 mm - Electromagnetic brake engages in 18 ms to retain position - Supports over 30 functions for control and feedback - Extensive application process packages available for diverse tasks - Lightweight and ergonomic Teach Pendant for better user experience
