Overview
The EVST ROBOTICS FlexArm S5 is a top collaborative robotic arm designed for small-scale assembly with a payload capacity of 5 kg and a reach of 900 mm. It emphasizes precision, achieving repeatability of ±0.02 mm, making it suitable for high-accuracy tasks. The arm is user-friendly, integrating seamlessly into existing operations while ensuring safety and flexibility in various assembly applications, especially in electronics and consumer goods.
Flagship features
- High-speed performance with a J2+J3 synthesis speed of 7200mm/s
- Excellent repeat positioning accuracy: J1: ±0.02mm; J2+J3 Synthesis: ±0.02mm; J4: ±0.01°
- Rated load moment: 0.02kg.m²; Maximum load moment: 0.3kg.m²
- Noise level under 75dBA, suitable for quiet environments
Specifications
Category: Cobot- Type
- six axis collaborative
- Axes
- 6
- Payload
- 6 kg
- Reach
- 917 mm
- Repeatability
- ±0.03 mm
- Weight
- 22 kg
- TCP speed
- 2 m/s
- IP rating
- IP54
- Safety cert.
- ISO/TS 15066
- Force limiting
- Yes
- F/T sensing
- none
- Teach pendant
- Ethernet/RS485 combination
Detailed specifications
Motion & kinematics1
- Dof Total
- 4
Other12
- Price Tier
- 20-40K
- Applications
- assembly
- Precision Mm
- ±0.02
- Operating Temp
- 0°C to 45°C
- Company Country
- CN
- Price Range Usd
- $28,000
- Deployment Notes
- Products exported to 100+ countries and regions worldwide.
- Industries Served
- electronics,consumer goods
- Lifting Capacity Kg
- 10
- Programming Interface
- no_code_gui,drag_and_drop
- Additional Information
- - High-speed performance with a J2+J3 synthesis speed of 7200mm/s - Excellent repeat positioning accuracy: J1: ±0.02mm; J2+J3 Synthesis: ±0.02mm; J4: ±0.01° - Rated load moment: 0.02kg.m²; Maximum load moment: 0.3kg.m² - Noise level under 75dBA, suitable for quiet environments
- Deployment Environment
- indoor
