Overview
HUNTER SE is an Ackermann front-steering line-control chassis featuring a simplified design with excellent industrial-grade quality. It adopts integrated motor control design, wide working temperature range, and a simple steel body. Equipped with hub motor structure technology, it achieves 4.8m/s speed with car-like front-wheel steering for precise motion control and minimal tire wear. Features front-wheel swing arm and independent rear suspension shock absorption, can climb 10° slopes, cross 50mm obstacles, carry 50kg payload, and operates in temperature range of -10~40°C.
Key facts
- Payload
- 50 kg
- Speed
- 4.8 m/s
- Battery
- 2 h
- Turn radius
- 150 mm
- API
- Yes
Detailed specifications
Other6
- Max Speed Ms
- 4.8
- Api Available
- true
- Max Speed M S
- 4.8
- Company Country
- CN
- Youtube Video Id
- kPFac7pM0pw
- Additional Information
- - Upgraded power system with all-steel body and latest wheeled motor structure technology - Modular design for easy reconfiguration and adaptability - Car-like structure with front-wheel steering for precise sports control and less tire wear - Supports expansion with aluminum T-slot rails for external sensors or kits - Open-source SDK and software resources for secondary development - CAN bus protocol for connections - Suitable for long-lasting, high-intensity work
