Overview
The JAKA MiniCobo is a versatile 6-axis industrial automation component designed for precision and flexibility. With a payload capacity of 1 kg and a reach of 580 mm, this lightweight cobot weighs only 9.4 kg and achieves a repeatability of 0.100 mm, making it ideal for various applications. Equipped with robust safety functions and multiple communication interfaces, the MiniCobo operates efficiently under a DC power supply while meeting stringent safety and compliance standards.
Key facts
- Payload
- 1 kg
- Reach
- 580 mm
- Speed
- 1.5 m/s
- Weight
- 9.4 kg
- IP rating
- —
- Battery
- —
- Power
- —
- Autonomy
- —
- Launch year
- 2014
- Price
- $13,312.5
- Status
- active
Detailed specifications
Motion & kinematics2
- Dof
- 6
- Repeatability Mm
- 0.1
Power & battery1
- Power Consumption W
- 150
Safety & certifications1
- Safety Certification
- CE (Machinery Directive 2006/42/EC, EMC, RED), RoHS, KCs, GB 11291.1-2011, ISO 10218-1:2011
Other16
- Price Tier
- 10-20K
- Applications
- Assembly, Deburring, Machine Tending, pick_and_place, Polishing
- Datasheet Url
- https://www.jakarobotics.com/products/jaka-minicobo/
- Max Speed M S
- 1.5
- Pricing Model
- purchase
- Operating Temp
- 0°C to 50°C
- Company Country
- DE
- Mounting Options
- At any angle
- Industries Served
- automotive, electronics, food_and_beverage, metal_manufacturing, service_and_hospitality, research_and_education
- Software Platform
- ENCY Robot
- Training Required
- none
- Fieldbus Protocols
- TCP/IP, Modbus TCP, Modbus RTU, Profinet, Ethernet/IP
- Availability Status
- available
- Extras.Contact Emails
- support@iautomatia.com
- Programming Interface
- proprietary_app
- Additional Information
- - Designed for precision and flexibility in industrial settings. - Ideal for applications requiring a lightweight cobot with high repeatability. - Supports robust safety functions such as Emergency Stop and Collision Protection. - Programmable with ENCY Robot for enhanced flexibility in automation tasks.
