Overview
The NAO V5 is a bipedal humanoid robot designed for research and education. Standing at 574 mm tall, it features a robust design made from ABS-PC/PA-66/XCF-30 material and weighs 5.4 kg. This model integrates various sensors and actuators enabling interaction and adaptability. The NAO robot is ideal for exploring robotics applications, programming, and is widely used in academic settings.
Specifications
Category: Education- Payload
- 5 kg
- Weight
- 5.4 kg
- Battery
- 1.5 h
- Launch year
- 2022
- Price
- Contact for quote
- Status
- active
Detailed specifications
Motion & kinematics5
- Dof
- 25
- Hand Dof
- 3
- Dof Total
- 25
- Dof Per Arm
- 7
- Dof Per Hand
- 3
Power & battery1
- Charge Time Hours
- 2
Sensors2
- Depth Mm
- 311
- Sensor Suite
- joint position sensors,contact and tactile sensors,video camera,infra-red,inertial unit
Compute2
- Ros Compatible
- true
- Onboard Compute
- Intel i7 processor
Safety & certifications2
- Grip Force N
- 50
- Safety Certification
- CE,ISO 13482
Other28
- Material
- ABS-PC/PA-66/XCF-30
- Width Mm
- 275
- Height Mm
- 574
- Price Tier
- 40-80K
- Applications
- research,education
- Sub Category
- bipedal
- Api Available
- true
- Auto Charging
- true
- Datasheet Url
- Preview PDF online
- Pricing Model
- purchase
- Model Variants
- NAO H25,NAO H21,NAO T14,NAO T2
- Operating Temp
- 0°C to 40°C
- Warranty Years
- 2
- Company Country
- US
- Lead Time Weeks
- 5
- Navigation Type
- lidar_slam
- Deployment Notes
- Deployed in various research institutions and commercial settings for experimentation and development.
- Walking Speed Ms
- 1
- Compatible Vision
- Kinect,Asus 3D sensor
- Industries Served
- education,research
- Software Platform
- NAOqi (Choregraphe)
- Training Required
- intermediate_1-5days
- Availability Status
- available
- Countries Available
- BR
- Lifting Capacity Kg
- 5
- Programming Interface
- code_python,teleoperation
- Additional Information
- Most widely used humanoid robot in the world.,Designed for Education and Research.,Integrated programming environment: Choreographe.,Multilanguage API and SDK available for researchers.,Suitable for children as young as 7 with intuitive programming.,Complementary curriculum materials for STEM subjects at KS1, KS2, KS3.,Used by universities and institutes worldwide for cutting-edge humanoid robotics research.,Offers face and object recognition, automatic speech recognition, text-to-speech in 19 languages, and whole body motion.,Case studies: T.U. Bergakademie Freiberg (human interaction research), Augsburg University (social behavior rapid prototyping).,Distributor/dealer: Active8 Robots (UK) – contact +44 (0)1761 234 376 for free demo.
- Deployment Environment
- indoor
