Overview
The NP-MD is an industrial collaborative robotic palletizer designed to automatically stack cartons, bags, bottles, and cans onto pallets in preset patterns. It is marketed for improving efficiency in manufacturing and logistics, featuring a safe anti-collision design, a simple visual programming interface, and a compact footprint. The system is highlighted for its ease of use, requiring no specialized programming knowledge, and its flexibility for quick redeployment. It is widely used across industries including food, pharmaceuticals, 3C electronics, daily chemicals, and e-commerce logistics. Safety mechanisms remain operational even in the event of a single-point failure.
Key facts
- Repeatability
- ±0.04 mm
Detailed specifications
Motion & kinematics1
- Repeatability Mm
- 0.04
Power & battery1
- Power Consumption W
- 3300
Other17
- Price Tier
- 40-80K
- Applications
- palletizing, pick_and_place, packaging
- Footprint Mm
- 1400*1610
- Sub Category
- floor-mounted
- Pricing Model
- purchase
- Force Limiting
- true
- Lift Height Mm
- 2400
- Operating Temp
- 0-55℃
- Deployment Notes
- Widely adopted across industries including food, pharmaceuticals, 3C electronics, daily chemical products, and e-commerce.
- Setup Time Hours
- 2
- Industries Served
- food_and_beverage, pharmaceutical, electronics, chemical, e-commerce
- Training Required
- basic_<1day
- Availability Status
- available
- Communication Method
- TCP/IP
- Palletizing Speed Cpm
- ≤ 8
- Programming Interface
- visual_block, no_code_gui
- Additional Information
- * **Key Differentiator:** Emphasizes extreme ease of use with a visual programming interface; basic functions learnable in 30 minutes, new palletizing paths can be set up in 5 minutes. * **Deployment Speed:** Can be fully installed and commissioned within two hours upon delivery to a factory. * **Throughput:** Operates at speeds of 8–14 cartons per minute. * **Pattern Capacity:** Supports configuration of up to 1,000 distinct palletizing paths. * **Pallet Size:** Accommodates pallets up to 1400 x 1400 mm. * **Versatile Handling:** Capable of palletizing cases, rows, full layers, and bags. Can simultaneously palletize two different product types. * **Safety:** Built-in anti-collision capabilities; safety protection remains functional even with a single-point failure. * **Compact Design:** Integrated structure with a small footprint for limited spaces. * **Power Supply:** Requires single-phase 220V/50HZ power.
