Overview
Our most popular cobot for lathes, with a slightly longer reach than OB7.
Key facts
- Payload
- 4 kg
- Reach
- 1250 mm
- DOF
- 7
- Repeatability
- ±0.1 mm
Detailed specifications
Motion & kinematics2
- Dof
- 7
- Repeatability Mm
- 0.1
Safety & certifications1
- Safety Certification
- IP30, IP41
Other19
- Price Tier
- 40-80K
- Applications
- machine_tending, packaging, gluing
- Datasheet Url
- https://hvhindustrial.com/pdfs/Productive-Robotics-OB7-Collaborative-Robots-Brochure.pdf
- Pricing Model
- purchase
- Model Variants
- OB7, OB7 Stretch, OB7 Max 8, OB7 Max 12, OB7 Max 16
- Operating Temp
- 0-37C (32-100F)
- Company Country
- US
- Deployment Notes
- Field proven since 2017 in shops across America.
- Setup Time Hours
- 1
- Compatible Vision
- OB Vision
- Industries Served
- manufacturing, automotive
- Software Platform
- Blaze
- Training Required
- none
- Fieldbus Protocols
- Ethernet IP, TCP/IP, Modbus
- Availability Status
- available
- Compatible Grippers
- Robotiq, OnRobot, Piab, Schmalz, PhD, Schunk
- Countries Available
- US
- Programming Interface
- no_code_gui, drag_and_drop
- Additional Information
- - Set up in about an hour and can teach a job in minutes using a physical demonstration. - Direct factory support available in the USA, including fast online assistance. - No programming is needed; users can guide the robot by hand for job teaching. - Offers unmatched flexibility due to its 7-axis design, allowing it to reach where 6-axis cobots can't. - Features a drag-and-drop interface on the 0 programming tablet for ease of use.
