Overview
The Fanuc CR-4iA is one of Fanuc's collaborative green robots. This small robot features a 4 kg payload and 550 mm reach. It can work side-by-side with an operator safely and efficiently without any safety fences or barriers. The Fanuc CR-4iA's structure is based off the proven design of the LR Mate series. Its highly sensitive contact detection and iRVision software allows for the robot to work seamlessly with a human. The CR-4iA also has versatile mounting options, making it ideal for a variety of production lines. This robot operates with the R-30iA controller.
Detailed specifications
Other13
- Motion Range J1
- ±340°
- Motion Range J2
- ±150°
- Motion Range J3
- ±354°
- Motion Range J4
- ±380°
- Motion Range J5
- ±200°
- Motion Range J6
- ±720°
- Max Speed J1 Deg S
- 250
- Max Speed J2 Deg S
- 250
- Max Speed J3 Deg S
- 250
- Max Speed J4 Deg S
- 250
- Max Speed J5 Deg S
- 250
- Max Speed J6 Deg S
- 250
- Extras.Contact Emails
- sales@fanuc.com
