CRP-RH14-10
Built by Guangdong Denop Intelligent Robot Technology · China
Not enough evidence to rank. Listed among 1,069 Industrial Arm robots; 246 carry a rank.
See the rankingRoboScore
Out of 100. Checks on sales, customers, specs and track record.
Strong evidence
No named customers yet. The score uses the rest of its record.
3 of 9 checks have data
Updated daily from public data. Missing data is skipped, never counted as zero.
What counts
Average of the 3 checks with data. Checks without data are left out.
Overview
Save Gas Collaborative Robot for Shipbuilding Industry Thick Plates Welding Robot for Steel
Flagship features
- Designed for material handling, cutting, assembly, marking, and grinding
- Features a dual-circuit safety emergency stop system with imported forced-disconnect relays for high reliability
- Built-in three-phase transformer for voltage isolation (380V/220V) and power stability
- Internal three-phase power filter to suppress external interference and prevent internal noise emission
- Uses high-flex robot-specific cables for the arm body
- Dual air line routing for gripper or tool actuation
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
At a glance
Specifications
From the makerCheckedEstimated- Small payload
- IP58
- Customization
- Teach pendant
- ISO 9409-1
- CE
- Metal processing, manufacturing
- 10 kg
- 1454 mm
- ±0.08 mm
- 170 kg
Carries more than 32% of 862 Industrial Arm robots with this spec
Reaches further than 46% of 732 Industrial Arm robots with this spec
More precise than 26% of 650 Industrial Arm robots with this spec
Heavier than 55% of 360 Industrial Arm robots with this spec
Detailed specifications
What it is built for3
- Applications
- welding
- vertical articulated
- Arc Welding
Movement & precision2
- 6
- Max Speed M S
- 3
Power & runtime1
- Power Consumption W
- 220
Controls & integration1
- Training Required
- basic_<1day
Safety & certification1
- -10ºC-40ºC
Buying & support5
- 10-20K
- purchase
- 1
- Lead Time Weeks
- 30
- Availability Status
- available
Other details12
- Speed
- 3000-4000mm/S
- Drive Mode
- Electric
- Speed Mm S
- 3000-4000
- Capacity Kg
- {"DNP-CR0905-GW":5,"DNP-CR1310-GW":10}
- Control Mode
- Point to Point Control
- Precision Mm
- {"DNP-CR0905-GW":"±0.02","DNP-CR1310-GW":"±0.03"}
- Control Method
- Digital
- Emergency Stop
- Yes
- Package Size Cm
- 1400.00 * 900.00 * 1300.00
- Maximum Arm Span Mm
- {"DNP-CR0905-GW":906,"DNP-CR1310-GW":1320}
- Package Gross Weight Kg
- 180
- Production Capacity Pieces Year
- 3000
Who uses it
No named customer yet
A customer is listed when a public source names them, or the maker adds them.
4 other robots in this category have one.
Add a customer →Where to buy
Get a price or reach an authorized seller.
No seller listed for your region yet. Ask for a quote.
Are you a distributor? List your company, free.
Every seller is shown equally. Placement is never sold and never affects a score.
Company milestones(estimated)
- 2022MilestoneDNP-CR0905-GW product video posted
- Not yet on fileMilestoneCompany profile available
Compare with
More by Guangdong Denop Intelligent Robot Technology
Frequently asked questions
- Who makes the CRP-RH14-10?
- The CRP-RH14-10 is developed by Guangdong Denop Intelligent Robot Technology, based in China.
- What type of robot is the CRP-RH14-10?
- The CRP-RH14-10 is a Industrial Arm made by Guangdong Denop Intelligent Robot Technology.
- How much does the CRP-RH14-10 cost?
- The CRP-RH14-10 is listed at US$8,000–17,000 in the Robolist catalogue, but this figure did not come from Guangdong Denop Intelligent Robot Technology. Contact them for a quote.
- What are the key specifications of the CRP-RH14-10?
- Key specifications of the CRP-RH14-10: arm class small payload, payload 10 kg, reach 1454 mm, repeatability ±0.08 mm, weight 170 kg.
