Overview
Basler AG与Orbbec奥比中光建立了技术合作伙伴关系，并将在德国斯图加特LogiMAT 2026上展示适用于物流和工厂自动化的Basler Stereo mini 3D相机。
Flagship features
- Integrates active and passive stereo vision capabilities for optimized performance
- Capable of operating in varying lighting conditions, ensuring reliability in both indoor and outdoor settings
- High frame rates of up to 30 fps at a depth resolution of 1280 x 800
- Multi-camera operations are simplified due to a rich frame synchronization mechanism
Specifications
Category: Industrial Arm- Arm class
- other
- IP rating
- IP67
- Programming
- Rest API, ROS, GenICam
- Safety cert.
- IP67
- Maturity
- commercial
- Industries
- robotics
Detailed specifications
Compute1
- Ros Compatible
- true
Other16
- Type
- object
- Title
- IndustrialArmExtraction
- $Schema
- View Link
- Required
- name,company_name,category,description
- Properties
- {"dof":null,"name":"Stereo mini camera","extras":{"baseline_mm":{"STM-501u":50,"STM-502u":50,"STM-951g":95,"STM-955g":95},"housing_size":{"STM-501u":"90 x 25 x 30 mm","STM-502u":"124 × 29 × 27 mm","STM-951g":"124 × 29 × 50 mm","STM-955g":"138 × 40 × 70 mm"},"io_connector":"8-pin pin header, single-row, 1.00 mm pitch","power_supply":{"common":"5 VDC via USB (requires port supporting 1.5 A)"},"working_range":{"STM-501u":"0.26–3 m","STM-502u":"0.25–6 m","STM-951g":"0.25–6 m","STM-955g":"0.31–10 m"},"contact_emails":[],"data_connector":{"common":"Type-C, receptacle, locking"},"depth_accuracy":{"STM-501u":"≤1.5% @ 2 m","STM-951g":"≤0.8% @ 2 m","STM-955g":"≤0.4% @ 2 m"},"depth_optical_filter":{"STM-501u":"None","STM-502u":"IR-pass","STM-951g":"Visible suppression","STM-955g":"Visible suppression"},"depth_image_resolution_frame_rate":{"common":"1280 x 800 @ 30 fps, 848 x 480 @ 60 fps"}},"category":"industrial_arm","reach_mm":null,"ip_rating":"IP67","price_usd":null,"weight_kg":0.097,"payload_kg":null,"price_tier":null,"description":"The Stereo mini camera series by Basler AG offers high-performance depth perception capabilities suited for various applications in industrial automation. With various models including USB and GigE options, these cameras provide accurate depth measurements, robust optical filters, and flexible connectivity. Their compact design is optimized for real-time image processing in a range of environments, featuring IP5X to IP67 protection ratings.","launch_year":null,"applications":["visual_inspection","assembly"],"company_name":"Basler AG","cycle_time_s":null,"sub_category":null,"api_available":null,"datasheet_url":null,"max_speed_m_s":null,"pricing_model":null,"hero_image_url":null,"model_variants":["STM-501u","STM-502u","STM-951u","STM-952u","STM-951g","STM-955g"],"operating_temp":"-10°C to 50°C","ros_compatible":null,"warranty_years":3,"company_country":"DE","lead_time_weeks":null,"controller_model":null,"deployment_count":null,"deployment_notes":null,"mounting_options":["Bottom: 1 × 1/4-20 UNC","Back: 2 × M4"],"repeatability_mm":null,"youtube_video_id":null,"industries_served":null,"software_platform":"ARM Linux, Windows","fieldbus_protocols":null,"availability_status":"available","compatible_grippers":null,"countries_available":null,"power_consumption_w":null,"safety_certification":["CE","FCC Part 15 Class B","RoHS"],"programming_interface":["code_ros"],"additional_information":" - Depth Accuracy: ≤1.5% @ 2 m for STM-501u; ≤0.4% @ 2 m for STM-955g\n - Depth Field of View: 90° x 65° ± 3° @ 2 m\n - RGB Image Resolution & Frame Rate: Up to 1920x1080 @ 30 fps\n - Operating Temperature: Ranges from -10°C to 50°C for certain models."}
- Applications
- bin_picking,machine_tending,order_picking
- Api Available
- true
- Datasheet Url
- View Link
- Model Variants
- Stereo mini,Stereo ace,Stereo visard
- Company Country
- DE
- Deployment Notes
- Notable customer deployments include automotive inspections and warehouse automation.
- Software Platform
- Basler pylon SDK
- Fieldbus Protocols
- GenICam,GigE Vision,Rest API
- Availability Status
- available
- AdditionalProperties
- false
- Additional Information
- - Integrates active and passive stereo vision capabilities for optimized performance. - Capable of operating in varying lighting conditions, ensuring reliability in both indoor and outdoor settings. - High frame rates of up to 30 fps at a depth resolution of 1280 x 800. - Multi-camera operations are simplified due to a rich frame synchronization mechanism.
