Battery-Power Transfer Cart
Built by Xinxiang Better Smart Transport Equipment · China
Updated May 2026·methodology
Overview
Our motorized material transfer facility is mainly designed to transport heavy cargo of industrial factory. It is powered by battery is installed inside the flat cart. The power supply provides power to DC traction motors through an electrical control system to control start, stop, advance, retreat, speed control, etc.
Flagship features
- Product is a battery-powered electric platform truck with cabin, essentially an AGV/AMR for material handling
- Offers pollution-free, environmentally friendly operation
- Energy efficiency savings claimed
- 180-degree swivel seat, bright LED headlights, power display
- Handbrake lever and footbrake for parking
- Capacity customizable up to 1-1,500 tons (likely range per variant)
Specifications
Category: Industrial Arm- Arm class
- other
- Payload
- 1500 kg
- Programming
- proprietary app
- Safety cert.
- CE, SGS ISO9001, SASO
- Maturity
- commercial
- Industries
- general_manufacturing, logistics
Detailed specifications
Power & battery5
- Battery Voltage
- 24,48,48,72,72
- Motor Power(Kw)
- 1,2.2,5,10,15
- Battery Capacity
- 180,180,330,440,600
- Power Consumption W
- 15000
- Running Distance For One Charge(Km)
- 6.5,4.8,4,3.8,3.2
Compute2
- Package Gross Weight
- 1000
- Ros Industrial Support
- none
Other26
- Material
- Steel
- Height Mm
- 500
- Duty Cycle
- continuous_24_7
- Price Tier
- $3,000-3,500
- Package Size
- 100.00cm * 200.00cm * 100.00cm
- Applications
- Steel Industry,Factory,Warehouse
- Sub Category
- electric_platform_truck
- Load Capacity
- 1-300ton
- Rated Load(T)
- 2,20,50,100,150
- Specification
- 2000*2000*500
- Max Speed M S
- 0.5
- Wheel Base(Mm)
- 1200,2800,4200,4900,7000
- Model Variants
- BXC-2t,BXC-20t,BXC-50t,BXC-100t,BXC-150t
- Warranty Years
- 2
- Table Size (Mm)
- {"Width(W)":[1500,2200,2500,2800,3000],"Height(H)":[450,550,650,900,1200],"Length(L)":[2000,4000,5500,6500,10000]}
- Company Country
- CN
- Special Function
- Anti-Explosion,Heat-Resistant,Lifting,Customized
- Walking Speed Ms
- 0.0333
- Youtube Video Id
- SsDzOiPDXbQ
- Production Capacity
- 50 Sets/Month
- Wheel Diameter (Mm)
- 270,350,500,600,600
- Rail Inner Gauge(Mm)
- 1200,1435,1435,2000,2000
- Running Speed (M/Min)
- 0,25,0,20,0,20,0,20,0,18
- Recommended Rail Model
- P15,P24,P43,QU100,QU100
- Additional Information
- - Product is a battery-powered electric platform truck with cabin, essentially an AGV/AMR for material handling. - Offers pollution-free, environmentally friendly operation. - Energy efficiency savings claimed. - 180-degree swivel seat, bright LED headlights, power display. - Handbrake lever and footbrake for parking. - Capacity customizable up to 1-1,500 tons (likely range per variant). - Tires: Vacuum/High Pressure (Front) + Dual Wheels (Rear). - Lead time 30-40 working days. - Certificate: CE, SGS ISO9001, SASO. - Minimal automation features; steering and control are manual/pedal-based, not autonomous. - No mention of navigation type, fleet software, or ROS support. - Price on request; enterprise pricing typical for this class of equipment.
- Running Time When Full Load
- 4.32,4,3.3,3.2,2.9
