CHITIC IIoT HMI ZT6000 Series
Built by Zhejiang Chitic Control Engineering Co., Ltd. · CN
Overview
Customization: Available. Screen Size: 7” 16:9 TFT LCD. Aspect Ratio: 1024×600.
Key facts
- Controller
- 600MHz ARM Cortex-A8
Detailed specifications
Power & battery4
- Input Power
- DC24V ,working range DC 9V~28V
- Power Protection
- Protected from thunderstrike and surging
- Power Consumption
- < 10W
- Power Down Allowed
- < 5mS
Compute1
- CPU
- 600MHz ARM Cortex-A8
Safety & certifications1
- Safety Certification
- CE & RoHS (EN61000-6-2:2005, EN61000-6-4:2007)
Other42
- RTC
- Built in
- Colors
- 24-bit
- Memory
- 128M Flash + 128M DDR3
- Origin
- China
- Weight
- About 560g
- Anti UV
- Not suitable to work in strong ultraviolet light (such as direct sunlight)
- Cooling
- Natural air cooling
- HS Code
- 8528521100
- COM Port
- COM1/COM3:RS232/RS485/RS422, COM2:RS485
- Ethernet
- Not Available
- LCD Life
- 50000 hours
- USB Port
- USB Slave 2.0 port*1,USB Host 2.0 port*1
- Backlight
- LED
- CE & RoHS
- Complied with EN61000-6-2:2005, EN61000-6-4:2007, RoHS, Surge Immunity:±1KV, EFT:±2KV,ESD:4KV, Air:8KV
- Dimension
- 204mm×145mm×33.8mm
- Enclosure
- ABS+PC
- Model NO.
- ZT8601
- Trademark
- CHINT
- Ce Marked
- true
- Brightness
- 450 cd/m2
- Customized
- Non-Customized
- Price Tier
- US$100.00 / Piece (1 Piece min order)
- Application
- Industrial Control System
- Screen Type
- Capacitive
- Touch Panel
- 4 wires resistive touch screen (Surface hardness 4H)
- Panel Cutout
- 192mm×138mm
- SD Card Port
- Available
- Specification
- 600MHz ARM Cortex-A8
- Operating Temp
- 0~50ºC
- Resolution(WxH)
- 1024×600
- Download Project
- USB Slave/U disk / Ethernet
- Controller Model
- 600MHz ARM Cortex-A8
- Transport Package
- Carton
- Industries Served
- Industrial Control System
- Operating Humidity
- 10~90%RH ( no condensate)
- Production Capacity
- 50000 Pieces/Year
- Storage Temperature
- -20~60ºC
- Vibration Endurance
- 10~25Hz (X,Y,Z direction 2G/30 minutes)
- Degree Of Protection
- Front IP65(with NEMA panel),Back IP20
- Operating Temperature
- 0~50ºC
- LCD Viewing Angle(T/B/L/R)
- 85'/85'/85'/85'
- Resistive Touch Screen Type
- Digital
