The CNC is a Industrial Arm developed by Jinan Artech Machinery (China), priced $25,000–$42,000 USD. Key specifications: arm class standard industrial, axes 8, payload 210 kg, reach 2700 mm.
Robo Index
Very strong evidence
5 of 10 signals present
Recomputed nightly from public data. Missing data is skipped, never zero-filled — and rankings are never for sale.
Weighted factors
average of the 5 scored · blanks don't count
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
Tell us what your job needs — payload, budget, region, must-have certifications — and we'll show how CNC measures up, requirement by requirement. The Robo Index (trust) above is shown for every buyer, regardless.
Overview
The CNC Robot from Jinan Artech Machinery is an industrial robotic arm designed for CNC machining and metal processing automation. It integrates with CNC machine tools to perform loading and unloading of workpieces, enabling lights-out manufacturing. The arm supports a range of payload capacities and reach configurations suitable for milling, turning, and grinding applications in small-to-medium manufacturing facilities.
Flagship features
- Unique Capability: Converts 3-axis/5-axis CNC toolpaths (G-code) into robot-arm trajectories using proprietary 'RobCode' software, enabling robotic machining with a standard industrial arm
- Software Ecosystem: Integrates with SmartMill1.9 multi-spindle automatic programming software and accepts 3D data from ZBrush, 3ds Max, Rhino, Maya, and 3D scanners
- Competitive Differentiator: Positions itself as an alternative to traditional 5-axis CNC routers for large-scale carving, moulds, and stone/foam applications
- Target Customer: Small-to-medium workshops needing flexible robot-based machining without dedicated CNC gantries
- Limitations: No payload, reach, repeatability, speed, or IP rating data provided; the page is focused on the software workflow rather than robot arm specs. Likely integrates third-party arms
- Note: This is a system integrator solution (Artech bundles a robot arm with their software) rather than a standalone robot arm model. Buyers should request specific arm specs from the supplier
Buyer decision signals
Viability
Company establishment
Availability
Specifications
Category: Industrial Arm- Arm class
- standard industrial
- Axes
- 8
- Payload
- 210 kg
- Reach
- 2700 mm
- Repeatability
- ±0.07 mm
- Mounting
- floor
- Controller
- KUKA KR210
- Programming
- offline programming
- Tool flange
- ISO 9409-1
- Force limiting
- No
- Maturity
- commercial
- Industries
- automotive, architecture, art production
Company profile
- Founded
- 2010
Detailed specifications
Motion & kinematics4
- Dof
- 8
- Axis Of Number
- 8 axis
- Length Of 8 Axis
- 300/ 500 cm
- Diameter Of 7 Axis Platform
- 100 cm
Other11
- Package
- wooden
- Inverter
- 11 kw
- Robot Arm
- KUKA
- Total Weight
- 1800 kg
- Applications
- milling
- Sub Category
- cnc_machining
- Warranty Years
- 1
- Milling Spindle
- 9 kw
- Company Country
- CN
- Procedure Types
- milling,engraving,sculpture,cutting,carving
- Additional Information
- - Unique Capability: Converts 3-axis/5-axis CNC toolpaths (G-code) into robot-arm trajectories using proprietary 'RobCode' software, enabling robotic machining with a standard industrial arm. - Software Ecosystem: Integrates with SmartMill1.9 multi-spindle automatic programming software and accepts 3D data from ZBrush, 3ds Max, Rhino, Maya, and 3D scanners. - Competitive Differentiator: Positions itself as an alternative to traditional 5-axis CNC routers for large-scale carving, moulds, and stone/foam applications. - Target Customer: Small-to-medium workshops needing flexible robot-based machining without dedicated CNC gantries. - Limitations: No payload, reach, repeatability, speed, or IP rating data provided; the page is focused on the software workflow rather than robot arm specs. Likely integrates third-party arms. - Note: This is a system integrator solution (Artech bundles a robot arm with their software) rather than a standalone robot arm model. Buyers should request specific arm specs from the supplier.
Where to buy
Get a price or reach an authorized seller — pick your region, then request a quote.
No authorized seller is listed for this robot yet — request a quote below and we’ll connect you with Jinan Artech Machinery Co., Ltd. or an authorized seller.
Request a quote — goes straight to Jinan Artech Machinery Co., Ltd..
Every authorized seller serving your region is shown equally — placement is never sold, and this data never affects a robot’s score. A seller’s absence here doesn’t mean they aren’t authorized.
Company milestones
- Aug 2015MilestoneCompany establishment
- 2010MilestoneEarlier company history mentioned
More videos
ART1325 CNC ROUTER WITH MACH3 SOFTWARE USB Port CONTROLLER simple working
CNC Router and Oscillating cutter With CCD Camera in one set ART1530EOT
ARTECH CNC Milling Robot Arm Milling Foam
ARTECH CNC Milling Robot Arm
In the news
- How Robotic Arms are Transforming Modern CNC Machine Operations
Dailyhunt · Jun 8, 2026
- How Robotic Arms are Transforming Modern CNC Machine Operations
Dailyhunt · Jun 7, 2026
- How Robotic Arms are Transforming Modern CNC Machine Operations
Analytics Insight · Jun 7, 2026
Frequently asked questions
- Who makes the CNC?
- The CNC is developed by Jinan Artech Machinery, based in China.
- What type of robot is the CNC?
- The CNC is a Industrial Arm made by Jinan Artech Machinery.
- How much does the CNC cost?
- The CNC is priced $25,000–$42,000 USD.
- What are the key specifications of the CNC?
- Key specifications of the CNC: arm class standard industrial, axes 8, payload 210 kg, reach 2700 mm, repeatability ±0.07 mm.
