CRP-RH14-10
Built by Guangdong Denop Intelligent Robot Technology · China
The CRP-RH14-10 is a Industrial Arm developed by Guangdong Denop Intelligent Robot Technology (China), listed at $8,000–$17,000 USD (unverified). Key specifications: arm class small payload, payload 10 kg, reach 1454 mm, repeatability ±0.08 mm.
RoboScore
Strong evidence
No confirmed deployment on record — this score reflects the rest of the record, not verified adoption.
3 of 9 signals present
Recomputed nightly from public data. Missing data is skipped, never zero-filled — and rankings are never for sale.
Weighted factors
average of the 3 scored · blanks don't count
Ranked #411 of 971 in the Industrial Arm standing.
See the standingWhere it has stood72 days · best #295 · worst #411
Nothing changed about this robot itself — what you can see is the field shifting around it, or its maker's news rising and ageing.
One reading per day since 3 Aug, when the current ordering began. The rank above is the reading for 14 Oct, taken against 971 robots — the standing itself is live, so a robot added since then counts there and not here yet.
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
Tell us what your job needs — payload, budget, region, must-have certifications — and we'll show how CRP-RH14-10 measures up, requirement by requirement. The RoboScore (trust) above is shown for every buyer, regardless.
Overview
Save Gas Collaborative Robot for Shipbuilding Industry Thick Plates Welding Robot for Steel
Flagship features
- Designed for material handling, cutting, assembly, marking, and grinding
- Features a dual-circuit safety emergency stop system with imported forced-disconnect relays for high reliability
- Built-in three-phase transformer for voltage isolation (380V/220V) and power stability
- Internal three-phase power filter to suppress external interference and prevent internal noise emission
- Uses high-flex robot-specific cables for the arm body
- Dual air line routing for gripper or tool actuation
Buyer decision signals
Viability
Company profile available
Price
purchase
Aggregated from public sources — unverified
Availability
Specifications
Category: Industrial Arm- Arm class
- small payload
- Payload
- 10 kg
- Reach
- 1454 mm
- Repeatability
- ±0.08 mm
- Weight
- 170 kg
- IP rating
- IP58
- Mounting
- Customization
- Programming
- teach pendant
- Tool flange
- ISO 9409-1
- Safety cert.
- CE
- Industries
- metal_processing, manufacturing
Top 63% of 851 models with this spec
Top 54% of 730 models with this spec
Top 71% of 646 models with this spec
Detailed specifications
What it is built for3
- Applications
- welding
- Sub Category
- vertical articulated
- Procedure Types
- Arc Welding
Movement & precision2
- Dof
- 6
- Max Speed M S
- 3
Power & runtime1
- Power Consumption W
- 220
Controls & integration1
- Training Required
- basic_<1day
Safety & certification1
- Operating Temp
- -10ºC-40ºC
Buying & support5
- Price Tier
- 10-20K
- Pricing Model
- purchase
- Warranty Years
- 1
- Lead Time Weeks
- 30
- Availability Status
- available
Other details12
- Speed
- 3000-4000mm/S
- Drive Mode
- Electric
- Speed Mm S
- 3000-4000
- Capacity Kg
- {"DNP-CR0905-GW":5,"DNP-CR1310-GW":10}
- Control Mode
- Point to Point Control
- Precision Mm
- {"DNP-CR0905-GW":"±0.02","DNP-CR1310-GW":"±0.03"}
- Control Method
- Digital
- Emergency Stop
- Yes
- Package Size Cm
- 1400.00 * 900.00 * 1300.00
- Maximum Arm Span Mm
- {"DNP-CR0905-GW":906,"DNP-CR1310-GW":1320}
- Package Gross Weight Kg
- 180
- Production Capacity Pieces Year
- 3000
Who runs it· deployment evidence
No deployment evidence on file
A deployment is recorded when a public source names the customer, or the maker confirms it. Nothing here counts against this robot.
4 other robots in this category have one.
Add a deployment →Where to buy
Get a price or reach an authorized seller — pick your region, then request a quote.
No authorized seller is listed for this robot yet — request a quote below and we’ll connect you with Guangdong Denop Intelligent Robot Technology Co., Ltd. or an authorized seller.
Request a quote — goes straight to Guangdong Denop Intelligent Robot Technology Co., Ltd..
Every authorized seller serving your region is shown equally — placement is never sold, and this data never affects a robot’s score. A seller’s absence here doesn’t mean they aren’t authorized.
Company milestones
- 2022MilestoneDNP-CR0905-GW product video posted
- —MilestoneCompany profile available
Compare with peers
More by Guangdong Denop Intelligent Robot Technology
Frequently asked questions
- Who makes the CRP-RH14-10?
- The CRP-RH14-10 is developed by Guangdong Denop Intelligent Robot Technology, based in China.
- What type of robot is the CRP-RH14-10?
- The CRP-RH14-10 is a Industrial Arm made by Guangdong Denop Intelligent Robot Technology.
- How much does the CRP-RH14-10 cost?
- The CRP-RH14-10 is listed at $8,000–$17,000 USD in the Robolist catalogue, but this figure is unverified and not confirmed by Guangdong Denop Intelligent Robot Technology — contact them for a quote.
- What are the key specifications of the CRP-RH14-10?
- Key specifications of the CRP-RH14-10: arm class small payload, payload 10 kg, reach 1454 mm, repeatability ±0.08 mm, weight 170 kg.
