Overview
EffiBOT is a collaborative autonomous mobile robot designed for logistics and warehouse operations. It improves logistics performance in factories and warehouses by functioning as a true logistic assistant. The robot can carry up to 300 kg or tow up to 500 kg, featuring 4 directional wheels for high maneuverability. Available in 2WD or 4WD configurations, it can traverse uneven floors and slopes up to 10%. With a driving speed up to 7 km/h (2 m/s), 360° environment analysis, and IP54 protection rating, EffiBOT provides both collaborative and fully autonomous handling capabilities.
Detailed specifications
Power & battery2
- Charge Time Hours
- 3.5
- Battery Capacity Kwh
- 1.632
Sensors2
- Lidar Count
- 2
- Safety Lidar Coverage Deg
- 360
Other27
- Width Mm
- 660
- Height Mm
- 550
- Length Mm
- 1450
- Industries
- general_warehousing,manufacturing
- Applications
- towing,order_picking,indoor_outdoor_conveying
- Max Speed Ms
- 1.6667
- Sub Category
- towing
- Payload Class
- heavy
- Fleet Software
- EffiFCS
- Model Variants
- EffiBOT,EffiBOT-XS,EffiBOT-P,EffiBOT-T
- Operating Temp
- 10°C to 45°C
- Company Country
- FR
- Price On Request
- true
- Industries Served
- general_warehousing,manufacturing
- Network Protocols
- wifi_4
- Software Platform
- EffiFCS
- Turning Radius Mm
- 1200
- Environment Rating
- indoor_outdoor_dock
- Obstacle Detection
- true
- Availability Status
- available
- Charging Time Hours
- 3.5
- Compatible Grippers
- Gripper,Gravity conveyor,Motorized conveyor,Manual hitch,Automatic hitch
- Countries Available
- Germany,Japan
- Floor Compatibility
- smooth_concrete,outdoor
- Pedestrian Detection
- human_aware
- Primary Applications
- order_picking,indoor_outdoor_conveying
- Additional Information
- - Co-developed with Manitou - Suitable for both indoor and outdoor use - Part of a range of AMRs including compact and stacker models - Designed for logistics applications such as order picking and conveying parts systems
