Overview
The new generation of robolink®: the integrated control system means that the RL-DP is ready for immediate use. With cables on the inside and individual, igus® not only relies on design. The robot's four-axis or five-axis versions are even more precise, faster and more durable than their predecessors. Due to the injection molding housing, the RL-DP is currently the most cost-effective among the robolink® robots.
Key facts
- Payload
- 3 kg
- Reach
- 790 mm
- DOF
- 5
- Repeatability
- ±0.5 mm
- TCP speed
- 0.1 m/s
Detailed specifications
Motion & kinematics2
- Dof
- 5
- Repeatability Mm
- 0.5
Power & battery1
- Power Consumption W
- 120
Compute1
- Ros Compatible
- true
Other12
- Price Tier
- 20-40K
- Applications
- assembly, machine_tending, lab_automation, visual_inspection
- Api Available
- true
- Datasheet Url
- https://www.igus.com/contentData/wpck/pdf/global/Robolink_DP_VERSION_DINA5.pdf
- Max Speed M S
- 0.1
- Model Variants
- RL-DP 4-axis, RL-DP 5-axis
- Lead Time Weeks
- 3
- Software Platform
- iRC software
- Fieldbus Protocols
- Modbus, TCP/IP
- Availability Status
- available
- Programming Interface
- proprietary_app
- Additional Information
- The robot arm is designed for immediate use with integrated control systems., Known for precision, speed, and durability improvements over predecessors., Cost-effective option among the robolink® products.
