Longway Smart Welding Robot
Built by DA LIAN MESCO STEEL · China
Updated May 2026·methodology
Overview
The Longway Smart Welding Robot is a portable, six-degree-of-freedom collaborative welding robotic arm designed for flexible, mobile welding in confined or semi-enclosed spaces. It features drag teaching programming, a human-computer interface, and a built-in welding process database with cloud support. The system includes a magnetic base for versatile mounting (upright, sideways, inverted), making it suitable for lightweight mobile welding tasks such as shipbuilding, steel structures, and general equipment manufacturing.
Detailed specifications
Motion & kinematics1
- Joint Speed Max Deg Per Sec
- 180
Power & battery6
- Wrist Power Supply
- 24V DC, 1.5A
- Welding Source Power Factor
- 0.94
- Welding Source Input Voltage
- 3~380VAC±20%
- Welding Source Unload Voltage V
- 73
- Welding Source Output Voltage Range V
- 12-45
- Welding Source Rated Output Voltage V
- 39
Other20
- Noise Db
- <65
- Warranty
- 1 Year
- Drive Mode
- Mechanical
- Control Mode
- Point to Point Control
- Input Output
- Power supply (24V, 1.5A) Digital IO, Analog IO, TCP/IP communication
- Welding Type
- Gas Shielded Arc Welding (CO2/Mixed Gas)
- No Code Capable
- true
- Training Required
- basic_<1day
- Production Capacity
- 200 pieces/month
- Adapted Welding Type
- Fillet weld, Butt weld, Circular arc weld
- Welding Machine Spec
- 350A/500A (according to plate thickness)
- Welding Source Model
- Titanmig X5
- Storage Dimensions Mm
- 1280*1040*1180
- Welding Source Insulation Grade
- H
- Welding Source Rated Capacity Kva
- 24
- Welding Source Enclosure Protection
- IP23S
- Welding Source Output Characteristic
- CV
- Welding Source Output Current Range A
- 30-500
- Welding Source Rated Output Current A
- 500
- Welding Source Rated Duty Cycle Percent
- 60
