Overview
The Model R2 AMR Robot is designed for versatile operation across various environments. It features an omnidirectional drivetrain and a twin LiDAR system for advanced navigation. The robot is equipped with an 8-degree-of-freedom robotic arm and a high-resolution LED display, making it suitable for a range of applications in autonomous mobile robotics.
Key facts
- Payload
- 2.5 kg
- Reach
- —
- Speed
- —
- Weight
- 55 kg
- IP rating
- —
- Battery
- 8 h
- Power
- —
- Autonomy
- —
- Launch year
- —
- Price
- —
- Status
- active
Detailed specifications
Motion & kinematics2
- Dof Total
- 8
- Dof Per Arm
- 8
Power & battery3
- Energy Stored Wh
- 1440
- Charge Time Hours
- 1
- Weight No Battery Kg
- 46
Sensors2
- Camera
- Stereo depth, 3D on a gimbal
- Sensor Suite
- stereo_camera, lidar, pressure_sensor, humidity_sensor, gas_sensor
Safety & certifications1
- Safety Certification
- CE Certified, UKCA Certified, FCC Part 15, ANSI R15.08, UN 38.3
Other18
- Width Mm
- 420
- Height Mm
- 1640
- Applications
- warehouse_transport, assembly, inspection, cleaning
- Connectivity
- Wi-Fi 6, Bluetooth 5.3
- Display Size
- 11.5-inch LED matrix
- Gripper Type
- Mechanical, interchangeable
- Datasheet Url
- https://www.quasi.ai/c2-cart-technical-specifications/
- Model Variants
- Standard, Large, Mini, PartPorter
- Operating Temp
- 0°C to 40°C
- Company Country
- US
- Navigation Type
- lidar_slam
- Available Options
- Four color choices, barcode scanner, precision manipulator
- Industries Served
- healthcare, pharmaceutical, retail, research
- Operating Altitude
- up to 10,000 feet (3000m)
- Lifting Capacity Kg
- 2.5
- Programming Interface
- proprietary_app
- Additional Information
- - All-wheel drive with omnidirectional mechanics - Stereo depth camera with 3D capabilities - Fast-charge capable: Up to 50% in 60 minutes - Removable rechargeable lithium-ion battery - Emergency stop button with Quasi AI Collision Detection - Over-the-air software updates - Various available options including a barcode scanner and bigger HD battery. - Designed and manufactured in the USA.
- Deployment Environment
- both
