Overview
Collaborative Palletizing Robot. As global manufacturing faces rising costs and labor shortages, the Collaborative Robot (Cobot) Palletizer has become an essential tool for modern factories. Unlike traditional industrial robots that require large spaces and safety fences, cobots are designed to work safely alongside human operators. This technology is ideal for industries such as food and beverage, pharmaceuticals, electronics, and e-commerce logistics, also an ultimate solution for manufacturers seeking to modernize their workforce through robust, user-friendly automation.
Specifications
Category: Cobot- Type
- six axis collaborative
- Axes
- 6
- Payload
- ≤ 25 kg
- Reach
- 1650 mm
- Repeatability
- ±0.05 mm
- Weight
- 50 kg
- TCP speed
- ≤ 3.5 m/s
- Safety cert.
- ISO/TS 15066
- Force limiting
- Yes
- F/T sensing
- none
- No-code
- Yes
- Teach pendant
- multi-touch teach pendant
Detailed specifications
Power & battery1
- Power
- 3kw
Other11
- HS Code
- 8479501100
- Trademark
- IPS
- Pallet Size
- L1200mm-W1200mm-H150mm
- Packing Size
- 2200mm*1450mm*1900mm
- Stacking Speed
- 6-12 Times/Min (According to The Products)
- Working Radius
- 1480mm/1680mm/1880mm/2080mm
- Height Required
- Workshop Should Be Higher Than 2.6 Meter
- Max Load Weight
- 20/30/50 Kg Optional
- Stacking Height
- Max 2500mm, Lift Height 600mm
- Production Capacity
- 500PCS/Month
- Availability Status
- available
