Overview
The R-ATV is Integra Robotics' purpose-built tracked unmanned ground vehicle for remote handling, payload transport, and precision manipulation in hazardous environments — defence, oil & gas, disaster response, and beyond.
Key specs
- Built for pallet picking, putaway and replenishment
- Used across defence, oil gas and smart agriculture
- Programmed through teach pendant
- Compatible with ROS
- Rated for operation at +10°C to +55°C
- Backed by a 1-year warranty
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
At a glance
Specifications
From the makerCheckedEstimated- 6.2 m/s
- Joystick,teleoperated
- lifepo4
Company profile
- Recorded funding
- US$1.1M· 1 round
Detailed specifications
What it is built for5
- Industries
- defence,oil gas,smart agriculture,disaster response
- Applications
- payload transport,precision manipulation
- Payload Class
- light
- Environment Rating
- indoor outdoor dock
- Primary Applications
- pallet picking,putaway,replenishment
Size & capacity4
- Width Mm
- 750
- Height Mm
- 650
- Length Mm
- 1200
- Floor Clearance Mm
- 260
Movement & precision2
- 6
- 30
Sensing & perception4
- Yes
- Camera Count
- 2
- rgb
- Yes
Power & runtime4
- No
- Auto Charging
- No
- 3
- No
Controls & integration4
- Yes
- Network Protocols
- wifi 4
- wifi
- teach pendant
Safety & certification2
- +10°C to +55°C
- Operating Temperature
- +10°C to +55°C
Buying & support3
- Datasheet Url
- View Link
- 1
- Price On Request
- Yes
Other details26
- Battery
- 40V / 30 Ah Lithium Phosphate (LiFePO₄)
- Sensors
- IMU, encoders
- Max Slope
- 30°
- Max Speed
- 10 km/h
- Wheelbase
- 820 mm
- Arm Payload
- 4 kg
- Comms Range
- 450 m LOS / 90 m non-LOS
- Min Runtime
- 30 min
- Motor Power
- 2 × 1000 W
- Ros Support
- ros2 vendor
- Drive System
- Tracked all-terrain drive system
- Gradeability
- 30°
- Charging Time
- 3 hours
- Communication
- 2.4 GHz wireless (450 m LOS / 90 m non-LOS)
- Vision System
- Dual 720p cameras (127° wide FOV / 87° FOV), day/night capability
- Unladen Weight
- 85
- Outdoor Capable
- Yes
- Ground Clearance
- 260 mm
- Manipulator Reach
- 1,300 mm
- Manipulator Speed
- Up to 0.3 rad/s per joint
- Visual Indicators
- status led
- Ground Clearance Mm
- 254
- Battery Capacity Kwh
- 35
- Opportunity Charging
- No
- Teleoperation Supported
- Yes
- No
Who uses it
No named customer yet
A customer is listed when a public source names them, or the maker adds them.
19 other robots in this category have one.
Add a customer →Where to buy
Get a price or reach an authorized seller.
No seller listed for your region yet. Ask for a quote.
Are you a distributor? List your company, free.
Every seller is shown equally. Placement is never sold and never affects a score.
Compare with
More by Integra Robotics
Integra Robotics in the news
the maker3 events · last 12 months
- Oct 13Integra Robotics builds modular robots for hazardous factory and defence work
- Aug 25From Screens to Streets: How Integra Robotics is Building India’s Physical AI Future
- Jun 9Integra Robotics raises $1.12 million to scale AI-powered robotics for defence and industry
Integra Robotics in the news
the maker3 events · last 12 months
News about Integra Robotics, the maker, not about this robot specifically, except rows marked this robot. Collected and classified independently across 9 outlets, so a maker cannot add to it. It never changes this robot's RoboScore (the evidence half of the RoboIndex) and it can move it up a board by at most 15 points. See all Integra Robotics news
Frequently asked questions
- Who makes the R-ATV?
- The R-ATV is developed by Integra Robotics, based in India.
- What type of robot is the R-ATV?
- The R-ATV is a Warehouse AMR made by Integra Robotics.
- How much does the R-ATV cost?
- Pricing for the R-ATV is not publicly listed. Contact Integra Robotics for a quote.
- What are the key specifications of the R-ATV?
- Key specifications of the R-ATV: top speed 6.2 m/s, navigation joystick,teleoperated, battery type lifepo4.
