Rail Bound Forging Manipulator
Built by Jinan Linteng Technology & Trade · China
Updated Jun 2026·methodology
Overview
Rail Bound Forging Manipulator (5-120Ton) for Metal Material Forging
Flagship features
- Operational modes: manual, semi-automatic, automatic, linkage
- Features a large-scale digital display for trim size visibility
- Supports rough and finish forging processes
- Adjustable parameters via keyboard for process customization
Specifications
Category: Industrial Arm- Arm class
- other
- Mounting
- rail-bound
- Controller
- Siemens PLC
- Safety cert.
- CE
- Industries
- metal_fabrication
Detailed specifications
Power & battery1
- Total Power (Kw)
- 89-220
Sensors1
- Sensor Suite
- pressure sensor, displacement sensor
Other26
- Ce Marked
- true
- Gauge (Mm)
- 2400-4500
- Industries
- metal_fabrication
- Price Tier
- 50K+
- Capacity (T)
- 1-120
- Applications
- forging
- Sub Category
- forging
- Datasheet Url
- Preview PDF online
- Max Speed M S
- 0.267
- Model Variants
- 15 Ton Rail Bound Forging Manipulator,10 Ton Hydraulic Forging Manipulator,8 Ton High Quality Hydraulic Forging Manipulator,100 Ton Rail Bound Forging Manipulator,Forklift Manipulator for Hot Die Forging Hydraulic Press Machine,Wheel Type Manipulator for Forging Machine,5 Ton Forging Hydraulic Press Manipulator,25 Ton Hydraulic Forging Manipulator,Hot Sale 10000t Open Die Hydraulic Forging Press +100t Manipulator,Forging Manipulator,20 Ton Forging Hydraulic Manipulator,40 T Forging Billet Handling Equipment,50 Ton Forging Workpieces Handling Equipment
- Warranty Years
- 1
- Company Country
- CN
- Procedure Types
- forging
- Max Moment (T.M)
- 10-90
- Price On Request
- true
- Grip Opening (Mm)
- {"max":"1900","min":"150"}
- Availability Status
- available
- Primary Applications
- forging
- Externality Size (Mm)
- {"Width (W)":"3400-5200","Height (H)":"3300-4390","Length (L)":"7380-10000"}
- Additional Information
- - Operational modes: manual, semi-automatic, automatic, linkage. - Features a large-scale digital display for trim size visibility. - Supports rough and finish forging processes. - Adjustable parameters via keyboard for process customization.
- Tongs Center Height (Mm)
- {"max":"1500-2500","min":"780-1000"}
- Travelling Speed (M/Min)
- 21-32
- Working Oil Pressure (Mpa)
- 10-20
- Tongs Rotation Speed (R/Min)
- 8-20
- Linked With Press In The Work
- Siemens PLC
- Horizontal Side Shift Of Tongs (Mm)
- 2140-3150
