The ultraArm P1 is a Cobot developed by Elephant Robotics (China). Key specifications: axes 4, repeatability ±0.1 mm, tcp speed 0.1 m/s, force limiting No.
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
Tell us what your job needs — payload, budget, region, must-have certifications — and we'll show how ultraArm P1 measures up, requirement by requirement. The Robo Score (trust) above is shown for every buyer, regardless.
Overview
The ultraArm P1 is a compact 4-DOF tabletop robotic arm from Elephant Robotics, designed for education and light-duty automation tasks. It offers a 650g payload, 360mm working radius, and ±0.1mm repeatability. The robot supports Python and C++ programming, runs on ROS 2, and offers extensive connectivity options including Wi-Fi, Bluetooth, USB 3.0, UART, and RS485. It is lightweight (<4.5kg) and designed for desktop installation, making it suitable for educational environments, research, and small-scale automation projects.
Buyer decision signals
Viability
Founded and joined HAX
Availability
Specifications
Category: Cobot- Axes
- 4
- Repeatability
- ±0.1 mm
- TCP speed
- 0.1 m/s
- Force limiting
- No
- API / SDK
- Yes
Company profile
- Founded
- 2016
Detailed specifications
Motion & kinematics2
- Joint Ranges
- {"J1":"-180°~+180°","J2":"-25°~+85°","J3":"-25°~+105°","J4":"-360°~+360°"}
- Max Joint Speed Deg S
- 180
Power & battery3
- Input Power
- DC 12V 5A
- Power Module
- High-precision stepper motors
- Power Adapter
- AC 100-240V 50-60Hz
Compute1
- Ros Compatible
- true
Other16
- Applications
- pick_and_place,visual_inspection,pcb_assembly
- Connectivity
- WiFi-2.4G,BT-2.4G/5G,USB 3.0,UART,RS485
- Sub Category
- tabletop
- Datasheet Url
- Preview PDF online
- Noise Level Db
- 60
- Operating Temp
- 0°~50°
- Working Humidity
- 5%~80%
- Industries Served
- education,research
- Installation Mode
- Mount to desktop
- Software Platform
- proprietary_app
- Training Required
- basic_<1day
- Working Radius Mm
- 360
- Availability Status
- available
- Programming Interface
- code_python,code_ros,proprietary_app
- Working Lifespan Hours
- 5000
- Max End Effector Speed Mm S
- 100
Where to buy
Get a price or reach an authorized seller — pick your region, then request a quote.
No authorized seller is listed for this robot yet — request a quote below and we’ll connect you with Elephant Robotics or an authorized seller.
Request a quote — goes straight to Elephant Robotics.
Every authorized seller serving your region is shown equally — placement is never sold, and this data never affects a robot’s score. A seller’s absence here doesn’t mean they aren’t authorized.
Company milestones
- 2016FundingFounded and joined HAX
- 2016MilestoneCompany founded in Shenzhen
- —MilestonemechArm series ROS support documented
- —MilestonemechArm product page published
- —LaunchmyCobot 280 Pi product page and Raspberry Pi cobot positioning
- —MilestoneRaspberry Pi forum discussion of myCobot-Pi 280
- —DeploymentHackster setup guide for myCobot 280 Pi
- —MilestonemyCobot 280 product family listing
Compare with peers
Frequently asked questions
- Who makes the ultraArm P1?
- The ultraArm P1 is developed by Elephant Robotics, based in China.
- What type of robot is the ultraArm P1?
- The ultraArm P1 is a Cobot made by Elephant Robotics.
- How much does the ultraArm P1 cost?
- Pricing for the ultraArm P1 is not publicly listed — contact Elephant Robotics for a quote.
- What are the key specifications of the ultraArm P1?
- Key specifications of the ultraArm P1: axes 4, repeatability ±0.1 mm, tcp speed 0.1 m/s, force limiting No, api / sdk Yes.
