Overview
Heavy-duty industrial robot with 420 kg payload capacity and 3100 mm maximum reach. Part of KUKA's KR FORTEC series, this all-rounder is energy-efficient and dynamic for handling applications. Features waterproof and dustproof wrist as standard, low maintenance requirements, and high reliability for production environments. Suitable for automotive and general industry sectors with modular design and flexible expansion options.
Key facts
- Payload
- 570 kg
- Reach
- 2,800 mm
- Speed
- —
- Weight
- 1,704 kg
- IP rating
- IP 65, IP 67
- Battery
- —
- Power
- —
- Autonomy
- —
- Launch year
- —
- Price
- —
- Status
- active
Detailed specifications
Motion & kinematics2
- Dof
- 6
- Repeatability Mm
- 0.04
Safety & certifications2
- Ip Rating Wrist
- IP67
- Safety Certification
- ISO 14644-1
Other11
- Arm Class
- heavy_payload
- Industries
- food_beverage
- Applications
- palletizing, food_and_beverage
- Sub Category
- palletizing
- Operating Temp
- 0 °C to 55 °C
- Cleanroom Class
- Class 5 at 40% override, Class 5 at 80% override
- Controller Model
- KR C5, KR C5 micro
- Mounting Options
- floor, ceiling, wall, tilted
- Additional Information
- - Holistic hygiene approach for ensuring food quality - Special varnish for easy cleaning and contamination detection - Global Customer Service support - Suitable for deep-freeze applications - Maintenance intervals identical to standard KUKA robots
- Temperature Range Max C
- 55
- Temperature Range Min C
- 0
