Overview
myCobot 320 M5は、myCobot製品の高度なバージョンで、主にメーカーや科学研究者に適しています。ユーザーのニーズに応じて二次開発を実施し、パーソナライズされたカスタマイズを実現できます。全体的に洗練されたデザイン、オールインワンデザインは、使いやすさ、安全性、経済性という3つの利点を持っており、コストパフォーマンスの高い選択肢です。
Detailed specifications
Motion & kinematics2
- Dof
- 6
- Repeatability Mm
- 0.5
Power & battery2
- Power
- 110~220V AC
- Power Supply
- 24V 5A; 120W
Compute1
- Ros Compatible
- true
Other20
- Base IO
- Digital-INPUT x3, Digital-OUTPUT x3
- Tool IO
- 12V/GND, Digital-INPUT X2, Digital-OUTPUT X2, 485Bus AB
- Material
- Industrial Nylon
- Motor Model
- mycobot Pro-320
- Noise Level
- <85 dB
- Applications
- education,research,pick_and_place,visual_inspection,scientific_research,display_scenarios
- Sub Category
- 6-axis cobot
- Api Available
- true
- Datasheet Url
- Preview PDF online
- Servo Encoder
- 12 Bit
- Working Range
- J1 +/- 170°, J2 +/- 160°, J3 +/- 160°, J4 +/- 160°, J5 +/- 170°, J6 +/- 175°
- Operating Temp
- 0~50°C
- Servo Gear Set
- Alloy Steel
- Servo Max Speed
- 180°/s
- Software Platform
- roboFlow, uiFlow, myStudio ROS, MoveIt, Python
- Communication Base
- Ethernet Port, typeC-Port
- Availability Status
- available
- Max Rotational Speed
- 180°/s
- Programming Interface
- drag_and_drop,visual_block,code_python,code_ros,proprietary_app
- Additional Information
- Smart barista to enlarge your business, can be applied in various commercial scenarios.,Perfect helper in photographic studio, much more accurate and stable.,Replace repetitive work, produce efficiently, create more value.,Continuously print out photos, the perfect combination of artistic creation and robot.,Helpful assistant in workshop, human and robot collaboration, infinite creativity.,Compact All-In-One design, super fit in AGV solutions, much more flexible.,Equipped with anti-collision detection function based on accurate dynamic model.,myStudio is a one-stop platform for robots of myRobot/myCobot.,International partners mentioned.
