The Apex 1400-L is a AGV developed by ForwardX Robotics (China). Key specifications: navigation lidar_slam, visual_slam, visual_slam, turn radius 2260 mm, fleet software Omni Fleet.
RoboScore
Adequate evidence
No confirmed deployment on record — this score reflects the rest of the record, not verified adoption.
5 of 9 signals present
Recomputed nightly from public data. Missing data is skipped, never zero-filled — and rankings are never for sale.
Weighted factors
average of the 5 scored · blanks don't count
Ranked #41 of 128 in the AGV standing.
See the standingWhere it has stood44 days · best #32 · worst #62
2 days carry something the board can name:
- 14 Aug RoboScore rose 0.45 — its evidence changed.
- 6 Sept Its maker's news lifted the score 2.70 — the board noticed.
One reading per day since 10 Aug, when the current ordering began. The rank above is the reading for 23 Sept, taken against 128 robots — the standing itself is live, so a robot added since then counts there and not here yet.
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
Tell us what your job needs — payload, budget, region, must-have certifications — and we'll show how Apex 1400-L measures up, requirement by requirement. The RoboScore (trust) above is shown for every buyer, regardless.
Overview
The Apex 1400-L is an autonomous pallet stacker forklift from ForwardX designed for high-density warehouse operations. It features laser SLAM and visual semantic positioning, a maximum payload of 1,400 kg, and a lift height of up to 1,600 mm standard (3,500 mm customizable). Equipped with 360° spatial awareness, safety bumper, and emergency stops, it is CE compliant and operates approximately 10 hours per charge.
At a glance
- Built for pallet picking, putaway and replenishment
- Used across e commerce and cosmetics
- Programmed through Omni Fleet
- Certified to CE
- Detects and avoids obstacles in its path
Buyer decision signals
Viability
ForwardX Robotics at Automate 2024
Availability
Specifications
Category: AGV- Navigation
- lidar_slam, visual_slam, visual_slam
- Turn radius
- 2260 mm
- Fleet software
- Omni Fleet
Company profile
- Confirmed funding
- US$92.0M· 2 rounds
- Founded
- 2016
Detailed specifications
What it is built for8
- Industries
- ecommerce fulfillment,general warehousing,other
- Amr Subtype
- forklift amr
- Applications
- pallet transport
- Sub Category
- pallet mover
- Payload Class
- heavy
- Industries Served
- e-commerce,cosmetics
- Environment Rating
- indoor only
- Primary Applications
- pallet picking,putaway,replenishment
Size & capacity6
- Width Mm
- 1050
- Height Mm
- 2080
- Length Mm
- 1830
- Floor Clearance Mm
- 85
- Min Aisle Width Mm
- 2200
- Load Center Distance Mm
- 600
Movement & precision1
- Obstacle Detection
- true
Controls & integration3
- Lidar Count
- 5
- Network Protocols
- wifi 5
- Software Platform
- Omni Fleet
Safety & certification3
- Emergency Stop Count
- 2
- Pedestrian Detection
- human aware
- Safety Certification
- CE
Buying & support3
- Model Variants
- Apex 1400-L,Apex C1500-L,Apex 2000,Apex 1500
- Price On Request
- true
- Availability Status
- available
Other details22
- Lidar
- 5 (TSA:s AMR:2+1)
- Wi Fi
- (IEEE 802.11a/b/g/n/ac): Yes (IEEE 802.11ax): Optional
- Wifi 6
- Optional
- Endurace
- ~10 hrs Per Charge
- Charging Mode
- DC CC-VC
- Safety Bumper
- Yes
- Charging Mode
- DC CC-VC
- Safety Bumper
- true
- Lift Height Mm
- 3500
- Positioning Mode
- Laser SLAM / Visual + Visual Semantics
- Fork Dimensions Mm
- 1160/170/60
- Ground Clearance Mm
- 85
- Pallet Compatibility
- Euro Pallets, Customized Pallets
- Runtime Loaded Hours
- 10
- Emergency Stop Button
- 2
- Pallet In Place Sensor
- 2
- Cellular Network 4g 5g
- Optional
- Fork Carriage Width Mm
- 680/560
- Cellular Network (4G/5G)
- Optional
- QR Code Cameras Downward
- N/A
- Safety Lidar Coverage Deg
- 360
- Pallet Off Position Sensor
- 2
Who runs it· deployment evidence
No deployment evidence on file
A deployment is recorded when a public source names the customer, or the maker confirms it. Nothing here counts against this robot.
2 other robots in this category have one.
Add a deployment →Where to buy
Get a price or reach an authorized seller — pick your region, then request a quote.
No authorized seller is listed for this robot yet — request a quote below and we’ll connect you with ForwardX Robotics or an authorized seller.
Request a quote — goes straight to ForwardX Robotics.
Every authorized seller serving your region is shown equally — placement is never sold, and this data never affects a robot’s score. A seller’s absence here doesn’t mean they aren’t authorized.
Company milestones
- May 2024MilestoneForwardX Robotics at Automate 2024
- May 2024MilestoneForwardX at Automate 2024
- Apr 2023LaunchLogiMAT 2023 Europe expansion launch
- 2022MilestoneProduction facility established
- 2021FundingSeries C1 funding
- 2016MilestoneFounded
- —DeploymentApex added after prior AMR results
- —LaunchApex R2000-L autonomous forklift introduced
Compare with peers
ForwardX Robotics in the news
the maker1 event · last 12 months
ForwardX Robotics Launches Brownfield Automation Whitepaper: Four Capabilities for Scaling AMRs in Existing Factories
ForwardX Robotics in the news
the maker1 event · last 12 months
News about ForwardX Robotics, the maker — not about this robot specifically, except rows marked this robot. Collected and classified independently across 3 outlets, so a maker cannot add to it. It never changes this robot's RoboScore — the evidence half of the RoboIndex — and it can move it up a board by at most 15 points. See all ForwardX Robotics news
Frequently asked questions
- Who makes the Apex 1400-L?
- The Apex 1400-L is developed by ForwardX Robotics, based in China.
- What type of robot is the Apex 1400-L?
- The Apex 1400-L is a AGV made by ForwardX Robotics.
- How much does the Apex 1400-L cost?
- Pricing for the Apex 1400-L is not publicly listed — contact ForwardX Robotics for a quote.
- What are the key specifications of the Apex 1400-L?
- Key specifications of the Apex 1400-L: navigation lidar_slam, visual_slam, visual_slam, turn radius 2260 mm, fleet software Omni Fleet.
