Overview
The ForwardX Max 1500-L is an autonomous mobile robot (AMR) designed for heavy-duty case and pallet handling in warehouse environments. It features laser SLAM and visual positioning, with optional QR code navigation, and has a maximum payload capacity of 1500 kg. The robot is equipped with four LiDAR sensors, front and right UWA cameras, and provides a lifting height of 60 mm to facilitate rack and pallet movement.
Key specs
- Built for pallet picking
- Used across e commerce and general warehousing
- Programmed through Omni Fleet
- Detects and avoids obstacles in its path
- Rated for operation at 0°C to 40°C
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
At a glance
Specifications
From the makerCheckedEstimated- Pallet mover
- 900 mm
- Lidar slam,vision,qr code
- CE
- lifepo4
- Purchase
- 8 h
Lasts longer than 28% of 272 Warehouse AMR robots with this spec
Company profile
- Recorded funding
- US$107M· 3 rounds
- Founded
- around 2016
Detailed specifications
What it is built for8
- Industries
- general warehousing,ecommerce fulfillment
- Applications
- pallet transport
- pallet mover
- Payload Class
- ultra heavy
- e-commerce,general warehousing
- Environment Rating
- indoor only
- Floor Compatibility
- smooth concrete,painted concrete,epoxy
- Primary Applications
- pallet picking,other
Size & capacity4
- Width Mm
- 800
- Height Mm
- 245
- Length Mm
- 1250
- Floor Clearance Mm
- 25
Movement & precision2
- 15
- Obstacle Detection
- Yes
Sensing & perception5
- Lidar Count
- 4
- Camera Count
- 3
- Computer Vision,LiDAR,360° Obstacle Detection
- Yes
- Yes
Power & runtime2
- Auto Charging
- Yes
- 3
Controls & integration6
- No
- Omni Fleet
- No
- Network Protocols
- wifi 5
- Software Platform
- Omni Fleet
- wifi,cellular 5g
Safety & certification3
- 0°C to 40°C
- Emergency Stop Count
- 2
- Pedestrian Detection
- generic obstacle
Buying & support8
- 20-40K
- Datasheet Url
- View Link
- Model Variants
- XYZBot 100,XYZBot 250,XYZBot 600
- Price Currency
- USD
- Pricing Models
- capex
- Price On Request
- Yes
- Availability Status
- available
- Service Network Density
- regional
Other details25
- Battery
- 48V, 72Ah
- Duration
- 8 hours (automatic charging available)
- Api Type
- open rest
- Body Weight
- 250 (kg)
- Ros Support
- none
- Load Capacity
- 1,500 (kg)
- Maximum Speed
- 2m/second
- Emergency Stop
- Yes
- Lift Height Mm
- 60
- Uptime Sla Pct
- 98.5
- Load Surface Mm
- 1200x830
- Fleet Management
- Yes
- Lifting Height Mm
- 60
- Positioning Modes
- Laser SLAM, Visual, Optional QR Code navigation
- 1340
- Visual Indicators
- status led,warning strobe
- Charge Cycles Rated
- 1000
- Ground Clearance Mm
- 25
- Battery Capacity Kwh
- 12
- Over The Air Updates
- Yes
- Predictive Maintenance
- threshold based
- Localization Accuracy Mm
- 10
- Obstacle Detection Range M
- 5
- External Dimensions (L×W×H)
- 1,250×850×245 (mm)
- Multi Robot Traffic Management
- dynamic optimization
Who uses it
No named customer yet
A customer is listed when a public source names them, or the maker adds them.
19 other robots in this category have one.
Add a customer →Where to buy
Get a price or reach an authorized seller.
No seller listed for your region yet. Ask for a quote.
Are you a distributor? List your company, free.
Every seller is shown equally. Placement is never sold and never affects a score.
Company milestones(estimated)
- May 2024MilestoneForwardX Robotics at Automate 2024
- Apr 2023LaunchLogiMAT 2023 Europe expansion launch
- 2022MilestoneProduction facility established
- 2021FundingSeries C1 funding
- 2016MilestoneFounded
- Not yet on fileDeploymentApex added after prior AMR results
- Not yet on fileLaunchApex R2000-L autonomous forklift introduced
Compare with
ForwardX Robotics in the news
the maker1 event · last 12 months
- Sep 2ForwardX Robotics Launches Brownfield Automation Whitepaper: Four Capabilities for Scaling AMRs in Existing Factories
ForwardX Robotics in the news
the maker1 event · last 12 months
News about ForwardX Robotics, the maker, not about this robot specifically, except rows marked this robot. Collected and classified independently across 3 outlets, so a maker cannot add to it. It never changes this robot's RoboScore (the evidence half of the RoboIndex) and it can move it up a board by at most 15 points. See all ForwardX Robotics news
Frequently asked questions
- Who makes the Max 1500-L?
- The Max 1500-L is developed by ForwardX Robotics, based in China.
- What type of robot is the Max 1500-L?
- The Max 1500-L is a Warehouse AMR made by ForwardX Robotics.
- How much does the Max 1500-L cost?
- Pricing for the Max 1500-L is not publicly listed. Contact ForwardX Robotics for a quote.
- When was the Max 1500-L launched?
- The Max 1500-L was launched in 2022.
- What are the key specifications of the Max 1500-L?
- Key specifications of the Max 1500-L: type pallet mover, min. aisle 900 mm, navigation lidar slam,vision,qr code, safety cert. CE, battery type lifepo4.
