Overview
9 kg, 1200 mm
Key facts
- Payload
- 9 kg
- Reach
- 1200 mm
- DOF
- 6
- Repeatability
- ±0.1 mm
- TCP speed
- 1 m/s
Detailed specifications
Motion & kinematics2
- Dof
- 6
- Repeatability Mm
- 0.1
Power & battery1
- Power Consumption W
- 100
Compute1
- Ros Compatible
- true
Safety & certifications1
- Safety Certification
- PL e Cat 4
Other22
- Price Tier
- 40-80K
- Applications
- machine_tending, pick_and_place, packaging, visual_inspection, gluing_dispensing, polishing
- Api Available
- true
- Datasheet Url
- https://www.doosanrobotics.com/pdf/catalog/External_DoosanRobotics_renew_eng.pdf
- Max Speed M S
- 1
- Force Limiting
- true
- Operating Temp
- 0°C to 50°C
- Warranty Years
- 2
- Company Country
- KR
- Lead Time Weeks
- 4
- Mounting Options
- floor, tabletop
- Setup Time Hours
- 1
- Compatible Vision
- Cognex, Basler
- Industries Served
- automotive, electronics, food_and_beverage
- Software Platform
- DART Platform
- Training Required
- basic_<1day
- Fieldbus Protocols
- Ethernet/IP, Profinet
- Availability Status
- available
- Compatible Grippers
- OnRobot RG2, Schunk PGN+
- Countries Available
- KR, US, EU
- Programming Interface
- drag_and_drop, no_code_gui
- Additional Information
- - 2x faster joint speed for productivity. - High-tech force sensors for delicate tasks on S models. - Protective casing available to shield against contaminants. - User-friendly smart pendant for easy control.
