Overview
The FMI852001 by Rozum Robotics is a compact high-torque brushless AC motor designed as a frameless rotor and stator kit. It features superior torque density, AC synchronous operation, and a hollow-shaft design. It is suitable for robotics, industrial equipment, commercial applications, healthcare, and printing/scanning.
Key specs
- Used across robotics, industrial equipment and commercial applications
- Rated for operation at 0 to 35°C
- Backed by a 1-year warranty
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
At a glance
Specifications
Specifications not yet on file.
Detailed specifications
What it is built for2
- Industries
- robotics,industrial equipment,commercial applications,healthcare,printing / scanning
- industrial-arm
Safety & certification3
- 0 to 35°C
- Temperature Range Max C
- 35
- Temperature Range Min C
- 0
Buying & support3
- Datasheet Url
- View Link
- 1
- Price On Request
- Yes
Other details26
- Power
- 405 W
- Length
- 32 mm
- Weight
- 455 g
- Diameter
- 75 mm
- Peak Torque
- 2.6 N·m
- RMS Current
- 9 A
- Rated Speed
- 4 300 RPM
- Peak Torque
- 2600 mNm
- Rated Speed
- 4300 RPM
- Rms Current
- 9 A
- Rated Torque
- 0.9 N·m
- Rated Torque
- 900 mNm
- No Load Speed
- 4 800 RPM
- Rotor Inertia
- 0.35 kg/cm²
- Supply Voltage
- 48 V
- Supply Voltage
- 48 V
- Stator Diameter
- 75 mm
- Mechanical Weight
- 455 g
- Performance Power
- 405 W
- Maximum Efficiency
- 90 %
- Speed Constant, Kv
- 100 RPM/V
- Terminal Inductance
- 155 µH
- Number Of Pole Pairs
- 10
- Motor Constant At 20° Ã
- 226 mN·m/√W
- Terminal Resistance At 20° Ã
- 0.13 Ω
- Torque Constant At 20° Ã, Kt
- 100 mN·m/A
