Overview
RC by Rozum Robotics is a series of high-class cost-efficient manipulators intended for manufacturing enterprises of all sizes, makers and innovators, research institutions. RC robots boast modular design and six degrees of freedom, which is almost as many as a human’s upper limb has. In practice that means that available degrees of freedom will alow you to cope with up to 95% of all production tasks. The machines consist of aluminium linking elements and self-designed servo motors embedded into joints. They can be integrated with a variety of end effectors, depending on intended use—grippers, welding equipment, laser tools, video cameras, etc. The built-in servo drives enable precise angular displacement of joints within the span from -360 to +360 degrees and positioning of the work tool with a thousandth degree accuracy. RC robotic arms are safe, require no costly protective caging and are allowed to work in direct contact with a human. Teaching trajectories by hand guiding makes setup, configuring, and adjusting the robots quick and easy, even for a user with no coding or engineering background. For advanced control, Rozum Robotics has implemented an Application Programming Interface (Python).
Key specs
- Built for spot welding, arc welding and material handling
- Used across automotive, electronics and food beverage
- Public API for integration
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
At a glance
Specifications
From the makerCheckedEstimated- Medium payload
- PULSE Software,Python API
- ISO 9409-1
- Automotive, Consumer Electronics, Food
- ±0.5 mm
More precise than 1% of 646 Industrial Arm robots with this spec
Detailed specifications
What it is built for3
- Industries
- automotive,electronics,food beverage,pharmaceutical,metal fabrication,plastics,logistics,aerospace,general manufacturing
- Applications
- Pick & Place,Machine tending,Painting,Injection molding,Lab testing,Welding,Gluing,Quality control,Polishing & deburring
- Primary Applications
- spot welding,arc welding,material handling,machine tending,assembly,painting,dispensing,palletizing,deburring polishing,cutting,press tending,foundry,cleanroom
Movement & precision1
- 6
Controls & integration1
- Yes
Buying & support4
- 40-80K
- Datasheet Url
- Preview PDF online
- Model Variants
- RC5,RC10
- Price On Request
- Yes
Other details17
- Max Load
- 6 kg, 12 kg
- Nominal Load
- 5 kg, 10 kg
- Working Radius
- 915 mm, 1300 mm
- Max Tcp Velocity
- 2 m/s
- Protection Class
- IP54
- Tool Changer Iso
- none
- Rated Load Capacity
- 5 kg
- Installation Support
- Yes, easy integration into existing production schemes with minimal changes.
- Standards Compliance
- ISO/TS 15066:2016, ГОСТ Р 60.1.2.3-2021
- Maximum Load Capacity
- 6 kg
- Programming Languages
- Python
- Rated Power Consumption
- 90-1300 W
- Risk Reduction In Tasks
- Reduction of risks and expenses associated with hazardous and harmful substances in tasks.
- Controller Model Specific
- Not specified
- Power Consumption Specific
- 90-1300 Вт, 90-1300 Вт
- Radius Of The Working Area
- 915 mm
- Programming Interface Specific
- ГИП "Пульс", API Python
Who uses it
No named customer yet
A customer is listed when a public source names them, or the maker adds them.
4 other robots in this category have one.
Add a customer →Where to buy
Get a price or reach an authorized seller.
No seller listed for your region yet. Ask for a quote.
Are you a distributor? List your company, free.
Every seller is shown equally. Placement is never sold and never affects a score.
Company milestones(estimated)
- 2015MilestoneFounded in Minsk
- Not yet on fileLaunchPULSE collaborative robot
Compare with
Frequently asked questions
- Who makes the RC10?
- The RC10 is developed by Rozum Robotics, based in Belarus.
- What type of robot is the RC10?
- The RC10 is a Industrial Arm made by Rozum Robotics.
- How much does the RC10 cost?
- Pricing for the RC10 is not publicly listed. Contact Rozum Robotics for a quote.
- What are the key specifications of the RC10?
- Key specifications of the RC10: arm class medium payload, repeatability ±0.5 mm, programming PULSE Software,Python API, tool flange ISO 9409-1, industries Automotive, Consumer Electronics, Food.
