Overview
The Fully Automated Collaborative Palletizing Robot with Pallet Positioning Pneumatic Control System.
Flagship features
- Competitive differentiator: Fence-free collaborative operation saves up to 60% floor space vs traditional fenced robots
- Unique capability: Dual-station palletizing of two different box types (A and B) simultaneously
- Rapid deployment: Operators can master the system in 5 minutes via graphical programming
- Advanced recipe management: Supports up to 60 distinct palletizing recipes for high-mix production
- Energy efficient: Consumes significantly less power than hydraulic or large-scale pneumatic systems
- Plug & play installation: Can be moved between production lines in hours
Specifications
Category: Industrial Arm- Arm class
- other
- Axes
- 4
- Payload
- 20 kg
- Reach
- 1800 mm
- Repeatability
- ±0.002 mm
- Weight
- 650 kg
- TCP speed
- 2.5 m/s
- IP rating
- IP53
- Mounting
- floor
- Controller
- KEBA
- Programming
- teach pendant,proprietary app
- Safety cert.
- CE
- Industries
- food_and_beverage, general_manufacturing, logistics
Detailed specifications
Motion & kinematics1
- Dof
- 4
Power & battery2
- Power Consumption W
- 3000
- Total Palletizing Power
- 3.0kw
Sensors1
- Maximum Compatible Pallet Size
- 1300mm*1200mm
Other25
- Origin
- Qingdao, China
- HS Code
- 84418090
- Trademark
- GOJON
- Ce Marked
- true
- Price Tier
- 10-20K
- Noise Level
- <80 Decibels
- Applications
- palletizing
- Cycle Time S
- 5
- Sub Category
- palletizing
- Max Speed M S
- 2.5
- Tray Placement
- Manual, One on The Left and One on The Right
- Main Unit Color
- Silver-Gray
- Company Country
- CN
- Procedure Types
- palletizing[1][2][3]
- Electrical Brand
- Simens, Delta
- Deployment Notes
- 1 hour to complete the installation and commissioning. Set up the new stack in 5 minutes.
- Designed Arm Span
- 1800mm
- Compatible Vision
- It has the function of identifying label direction.
- Palletizing Height
- Maximum Palletizing Height 2000mm
- Production Capacity
- 1000sets
- Main Unit Dimensions
- L1732mm*W1300mm*H2644mm
- Extras.Contact Emails
- 516507987@qq.com
- Additional Information
- - Competitive differentiator: Fence-free collaborative operation saves up to 60% floor space vs traditional fenced robots. - Unique capability: Dual-station palletizing of two different box types (A and B) simultaneously. - Rapid deployment: Operators can master the system in 5 minutes via graphical programming. - Advanced recipe management: Supports up to 60 distinct palletizing recipes for high-mix production. - Energy efficient: Consumes significantly less power than hydraulic or large-scale pneumatic systems. - Plug & play installation: Can be moved between production lines in hours. - ROI period: 12-18 months (vs 24-36 months for traditional industrial robots). - Supply chain: Uses well-known global brands for core components (KEBA, SICK, Meanwell). - Target industry: End-of-line packaging in food, beverage, consumer goods, and industrial component industries. - Noise level: <80 dB. - Palletizing height: up to 2000 mm. - Max pallet size: 1300x1200 mm. - Adaptive palletizing speed: 8-12 cycles/min (product-dependent). - Power supply: 220V±10%, 50Hz±5%. - Air supply: 0.5-0.7 MPa, reference air consumption 240-460 L/min. - Shipping: packed in wooden case (2200x1450x1900 mm) for international transport.
- Palletizing Speed Design
- 8-12 Times/Minute
- Logistics Wooden Crate Dimensions
- L2200mm*W1450mm*H1900mm
