H-850T Swing Arm Robot
Built by Dongguan Tongyi Plastic Machinery Manufacturing Co.,Ltd · CN
Overview
Swing-arm robot for sprue picking on horizontal/vertical injection molding machines 30-150T. Pneumatic drive, up to 2kg payload, 850mm vertical stroke, take-out time 1.9s.
Detailed specifications
Power & battery1
- Power Supply
- AC 220V±10%, 50/60Hz
Compute1
- Crosswise Stroke Mm
- 120
Safety & certifications1
- Safety Certification
- CE,ISO
Other31
- Type
- Telescopic
- Price Tier
- 10-20K
- Oem Support
- true
- Applications
- pick_and_place
- Control Mode
- PLC
- Drive System
- Air Cylinder
- Sub Category
- swing arm robot / pneumatic sprue picker
- Customization
- Available
- Payment Terms
- 70% prepayment, 30% balance before delivery
- Pricing Model
- purchase
- Imm Range Tons
- 160-300
- Model Variants
- H-650,H-750T,H-850T
- Muscle Size Kg
- 1–11
- Warranty Years
- 1
- Lead Time Weeks
- 3
- Swing Angle Deg
- 60-90
- Take Out Time S
- 1.9
- Air Pressure Mpa
- 0.5-0.7
- Deployment Notes
- Used for sprue/runners/finished parts removal on IMMs 30-150T.
- Dry Cycle Time S
- 6.5
- Industries Served
- plastics,injection_molding
- Machine Weight Kg
- 50
- Training Required
- basic_<1day
- Vertical Stroke Mm
- 850
- Availability Status
- available
- Countries Available
- China,Vietnam
- Programming Interface
- teach_pendant
- Additional Information
- - Uses high-strength aluminum alloy with linear guide rails for light weight and long life.,- X-axis rotates 90° for easy mold change; equipped with hydraulic shock absorber.,- Y-axis has pneumatic cylinder fall prevention device.,- Z-axis adjustable 45°–90° for placing finished parts on operator or non-operator side.,- External safety signal interlock with IMM prevents mold lock if parts not removed.,- Can feed sprue directly to beside-in-press granulator for immediate recycling.,- Palm controller with friendly interface; open teaching mode for custom action programs.,- Wrist rotates 90° (H-650) or 180° (via jig rotation); sensor detects product presence.,- Manufacturer: Dongguan Tongyi Plastic Machinery, established 2005, 34 employees.,- 6 production bases (2 South China, 1 Central China, 2 East China, 1 Vietnam).,- After-sales service: engineers assist remote installation.,- Lead time: within 15 workdays (both peak and off season).,- Packaging: wooden case.,- HS Code: 8428904000.
- Jig Rotation Angle Deg
- 180
- Air Consumption NI Cycle
- 14
- Production Capacity Per Year
- 1000
