Overview
14 kg, 900 mm
Key facts
- Payload
- 14 kg
- Reach
- 1420 mm
- DOF
- 6
- Repeatability
- ±0.04 mm
- TCP speed
- 1.5 m/s
Detailed specifications
Motion & kinematics2
- Dof
- 6
- Repeatability Mm
- 0.04
Power & battery1
- Power Consumption W
- 3600
Safety & certifications1
- Safety Certification
- CE, ISO
Other12
- Price Tier
- 40-80K
- Applications
- additive_manufacturing, assembly, dispensing, material_handling, remote_tcp, welding
- Datasheet Url
- https://hanwharobotics.com/uploads/product/202506/202506171607320000.pdf
- Max Speed M S
- 1.5
- Company Country
- KR
- Deployment Notes
- Notable deployments include applications in Additive Manufacturing and collaborative assembly. NASA has utilized RoboDK for multi-robot inspections enhancing quality control processes.
- Mounting Options
- floor, wall, ceiling
- Fieldbus Protocols
- TCP/IP, Modbus TCP, EtherNet/IP
- Availability Status
- available
- Extras.Contact Emails
- sales@hanwharobotics.com, info@hanwharobotics.com, contact@hanwharobotics.com
- Programming Interface
- teach_pendant
- Additional Information
- - Holds the highest payload and widest reach in the HCR series. - Industry-leading joint speeds for increased efficiency. - Slim design for better integration in workspaces. - Operating noise level ≤65dBA.
