Overview
The modular truss robot (M series) is a standard product developed by SIASUN according to market demand, with a total of six sub-series, suitable for different applications. All truss robots are composed of standardized modular units, which are flexible in combination, easy to install, and highly adaptable.
Key facts
- Payload
- 2500 kg
- Reach
- 2500 mm
- Repeatability
- ±0.5 mm
Detailed specifications
Motion & kinematics2
- X Axis Stroke
- can be extended infinitely
- Repeatability Mm
- 0.5
Other12
- Max Speed
- 240m/min along the X-axis, Y-axis, and Z-axis
- Price Tier
- 40-80K
- Applications
- machine_tending, material_handling, palletizing
- Sub Category
- truss_robot
- Max Speed M S
- 4
- Modular Design
- good interchangeability and versatility
- Additional Axes
- can be added
- Company Country
- CN
- Mounting Options
- floor, ceiling
- Availability Status
- available
- Additional Information
- - Modular and standardized design for flexible configuration - Capable of handling heavy loads up to 2500 kg over long distances - High repeat positioning accuracy to minimize cycle time variability - Suitable for integration with various sensors and safety systems
- Standard Product Load Ranges
- 1 to 5000 kg
