Overview
The Industrial Robot ROKAE NB25-25/1.8 is a versatile six-axis robotic solution designed for demanding automation tasks. With a payload capacity of 30 kg and a reach of 1813 mm, this robot offers high precision with a repeatability of 0.05 mm and a maximum speed of 492 °/s on axis 4. Equipped with advanced safety functions and a robust Titanite control system, the ROKAE NB25-25/1.8 is suitable for various mounting orientations, making it an ideal choice for modern industrial applications.
Key facts
- Payload
- 30 kg
- Reach
- 1,813 mm
- Speed
- —
- Weight
- 256 kg
- IP rating
- IP65
- Battery
- —
- Power
- —
- Autonomy
- —
- Launch year
- —
- Price
- —
- Status
- active
Detailed specifications
Motion & kinematics1
- Repeatability
- 0.05 mm
Power & battery2
- Power Supply
- 3×380VAC (3L + N + PE)
- Power Consumption
- 9100
Sensors1
- Maximum Speed
- 492 °/s (axis 4)
Safety & certifications2
- Certifications
- CE, KC, EAC
- Safety Functions
- Collision detection; safety zones; force and power monitoring; collaboration mode
Other4
- Axes
- 6
- Controller
- XBC5 series (Titanite control system)
- Mounting Orientation
- Floor, Ceiling
- Communication Interfaces
- Profinet, Ethernet/IP, TCP/IP, others optional (e.g. CC-Link, DeviceNet, RS-232)
