Overview
The KR 16 R1610-2 is an industrial robot with 16 kg payload and 1612 mm reach from the KR CYBERTECH family. Engineered for handling, assembly, and light palletizing with high precision and dynamic movements. Features IP 65 protection, compact design for maximum integration density, and mountable at multiple angles for flexible cell concepts.
Specifications
Category: Industrial Arm- Arm class
- standard industrial
- Axes
- 6
- Payload
- ≤ 16 kg
- Reach
- ≤ 1612 mm
- Repeatability
- ±0.04 mm
- Weight
- 255 kg
- IP rating
- IP65
- Mounting
- floor, ceiling, wall
- Controller
- KR C4
- Safety cert.
- IEC61340-5-1, ANSI/ESD S20.20
- Force limiting
- No
- Maturity
- commercial
- Industries
- automotive, metal_fabrication
Detailed specifications
Motion & kinematics2
- Dof
- 6
- Max Joint Speed Deg S
- 630
Other12
- Price Tier
- 40-80K
- Applications
- assembly,arc_welding,pick_and_place
- Datasheet Url
- View Link
- Pricing Model
- purchase
- Operating Temp
- 5°C to 55°C
- Price Currency
- EUR
- Company Country
- DE
- Price On Request
- false
- Availability Status
- available
- Additional Information
- Hollow design for work in confined spaces.,High positioning accuracy.,Minimal maintenance and low operational costs.
- Temperature Range Max C
- 55
- Temperature Range Min C
- 5
