Overview
Lite 6 is a compact collaborative robot starting at $2,999, designed with a maximum payload of 600 grams, speed of 0.5 m/s, and reach of 440 mm. It is engineered for easy setup and intuitive software, making it an accessible option for new automation users and laboratory applications.
Flagship features
- Designed for space-saving applications
- Ideal for tasks requiring flexibility and efficiency
- Open-source Python/C++ SDK enables flexibility
- ROS/ROS2 packages ensure smooth deployment
- Dedicated online support available
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
At a glance
Specifications
From the makerCheckedEstimated- Six axis collaborative
- 6
- CE
- Yes
- Joint level all
- Yes
- no pendant (browser UI)
- Yes
- Yes
97% of cobot robots have it
88% of cobot robots have it
63% of cobot robots have it
90% of cobot robots have it
- 0.6 kg
- 440 mm
- ±0.5 mm
- 7.2 kg
- 0.5 m/s
Carries more than 3% of 430 Cobot robots with this spec
Reaches further than 2% of 402 Cobot robots with this spec
More precise than 2% of 372 Cobot robots with this spec
Heavier than 6% of 259 Cobot robots with this spec
Faster than 9% of 242 Cobot robots with this spec
Detailed specifications
What it is built for2
- Applications
- pick and place
- tabletop
Sensing & perception1
- Yes
Power & runtime1
- Power Consumption W
- 200
Controls & integration6
- Yes
- Software Platform
- UFACTORY Studio
- Training Required
- none
- Fieldbus Protocols
- Modbus RTU
- Compatible Grippers
- UGripper Lite,Vacuum Gripper Lite
- teach pendant,drag and drop,code python,code ros
Safety & certification1
- 0°C to 50°C
Buying & support5
- 10-20K
- purchase
- Model Variants
- Lite 6 (Without Accessories),Lite 6 Kit (Includes Lite Gripper & Lite Vacuum Gripper)
- 1
- Availability Status
- available
Other details17
- Footprint
- Ø 126mm
- Materials
- Aluminum, Carbon Fiber
- Motor Type
- DC Brushless
- Joint Limits
- {"Joint 1":"±360°","Joint 2":"±150°","Joint 3":"-3.5°~300°","Joint 4":"±360°","Joint 5":"±124°","Joint 6":"±360°","Joint 7":"±360°"}
- Control Box Io
- 16*DI/16*DO/2*AI/2*AO
- End Effector Io
- 16*DI/16*DO/2*AI/2*AO
- Additional Details
- {"robot_specs":{"Footprint":"Ø 126mm","Materials":"Aluminum, Carbon Fiber","Robot_Mounting":"Any","End_Effector_I/O":"16*DI/16*DO/2*AI/2*AO","Power_Consumption":"Min 8.4 W, Typical 200 W, Max 400 W","Input_Power_Supply":"24V DC，16.5A","Base_Connector_Type":"M5*5","ISO_Class_Cleanroom":5,"Ambient_Temperature_Range":"0-50°C","End_Effector_Communication_Protocol":"Modbus RTU(rs485)"}}
- Communication Mode
- Ethernet
- Input Power Supply
- 24V DC，16.5A
- Base Connector Type
- M5*5
- Iso Class Cleanroom
- 5
- Digital Twin Support
- proprietary only
- Sdk Language Support
- Python,C++
- Ambient Temperature Range
- 0-50°C
- Power Consumption Min Max
- Min 8.4 W, Typical 200 W, Max 400 W
- Offline Programming Support
- proprietary simulator
- End Effector Communication Protocol
- Modbus RTU(rs485)
Who uses it
No named customer yet
A customer is listed when a public source names them, or the maker adds them.
14 other robots in this category have one.
Add a customer →Where to buy
Get a price or reach an authorized seller.
No seller listed for your region yet. Ask for a quote.
Are you a distributor? List your company, free.
Every seller is shown equally. Placement is never sold and never affects a score.
Company milestones(estimated)
- 2018LaunchxArm 7 announced for launch
- 2018LaunchxArm 7 launch planned for 2018
- 2013LaunchuArm introduced
- 2013MilestoneCompany founded
- Not yet on fileMilestonexArm 6 marketed for R&D and engineering use
- Not yet on fileMilestonexArm integration guide for production lines
- Not yet on fileMilestoneUFACTORY 850 product page available
- Not yet on fileMilestoneFounded in May 2013
Compare with
UFACTORY in the news
the maker1 event · last 12 months
- Aug 6TOAST and UFACTORY Launch Global Partnership
UFACTORY in the news
the maker1 event · last 12 months
News about UFACTORY, the maker, not about this robot specifically, except rows marked this robot. Collected and classified independently across 1 outlet, so a maker cannot add to it. It never changes this robot's RoboScore (the evidence half of the RoboIndex) and it can move it up a board by at most 15 points. See all UFACTORY news
Frequently asked questions
- Who makes the Lite 6?
- The Lite 6 is developed by UFACTORY, based in China.
- What type of robot is the Lite 6?
- The Lite 6 is a Cobot made by UFACTORY.
- How much does the Lite 6 cost?
- The Lite 6 is priced at US$1,199–4,200.
- What are the key specifications of the Lite 6?
- Key specifications of the Lite 6: type six axis collaborative, axes 6, payload 0.6 kg, reach 440 mm, repeatability ±0.5 mm.
