#12 of 72 ranked Education robots (131 listed)
See the rankingWatch it work
1 video · from DJIRoboScore
Out of 100. Checks on sales, customers, specs and track record.
Strong evidence
No named customers yet. The score uses the rest of its record.
5 of 9 checks have data
Updated daily from public data. Missing data is skipped, never counted as zero.
What counts
Average of the 5 checks with data. Checks without data are left out.
Overview
The RoboMaster S1 is an educational robot that introduces users to AI and programming concepts. It is equipped with a range of sensors, a camera, and a customizable interface, allowing students to learn robotics in a hands-on way.
Key specs
- Built for stem education
- Used across education
- Navigates using vision
- Programmed through drag and drop and python
- Public API for integration
- Compatible with ROS
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
At a glance
Specifications
From the makerCheckedEstimated- 1 kg
- 3.5 m/s
- 3.5 kg
- 0.58 h
- Semi-autonomous
- 2019
- Up to US$549
- Active
Detailed specifications
What it is built for3
- Applications
- pick and place,sorting
- robotics kit
- education
Size & capacity1
- Height Mm
- 270
Movement & precision3
- 2
- Max Speed M S
- 3.5
- vision
Sensing & perception5
- Camera Count
- 1
- FPV camera,31 sensors,infrared and nontoxic gel bead Blaster,six PWM ports,one Sbus control port
- Yes
- Yes
- on device
Power & runtime2
- Auto Charging
- No
- 1.5
Controls & integration8
- Yes
- Max Fleet Size
- 6
- Yes
- Compatible Vision
- 6 AI vision recognition modes: line, markers, people, gestures, applause, S1 robots
- Software Platform
- RoboMaster App / DJI SDK
- Training Required
- none
- wifi
- code python,visual block,drag and drop
Safety & certification2
- -10 to 40 °C
- CE
Buying & support6
- <10K
- Datasheet Url
- Preview PDF online
- purchase
- Model Variants
- DJI ROMO P (Water Tank Version),DJI ROMO A (Water Tank Version)
- Availability Status
- available
- Countries Available
- AU,AT,BE,BG,HR,CZ,DK,EE,FI,FR,DE,GR,HU,IE,IT,LV,LI,LT,LU,MT,MC,NL,NO,PL,PT,RO,SK,SI,ES,SE,CH,GB,CA,PR,US,CN,HK,JP,MO,SG,KR,TW,NZ,PH,MY,TH
Other details44
- FOV
- 120°
- IOS
- iOS 10.0.2 or later
- Input
- 100-240 V, 50-60Hz, 1A
- Energy
- 25.92 Wh
- Output
- 12.6 V=0.8A or 12.6 V=2.2A
- Sensor
- CMOS 1/4", Effective pixels: 5 MP
- Weight
- 0.12-0.17 g
- Android
- Android 5.0 or later
- Voltage
- 12.6 V
- Capacity
- 2400 mAh
- Diameter
- 5.9-6.8 mm
- Max Torque
- 0.25N·m
- Latency [2]
- 80-100ms (Wi-Fi), 100-120ms (Router)
- Average Load
- 430
- Battery Type
- LiPo 3S
- Photo Format
- JPEG
- Video Format
- MP4
- Rated Voltage
- 28 W
- Operating Mode
- Wi-Fi, Router
- Effective Width
- 360° (indoor)
- Max Output Power
- 19 W
- Mechanical Range
- Pitch: -24° to +41°, Yaw: ±270°
- Live View Quality
- 720p/30fps
- Max Video Bitrate
- 16 Mbps
- Controllable Range
- Pitch: -20° to +35°, Yaw: ±250°
- Battery Life In Use
- 35 minutes
- Effective Range [1]
- 6 m (indoor), 3 m (indoor)
- Recommended Routers
- TP-Link TL-WDR8600; TP-Link TL-WDR5640 (China), TP-Link Archer C7; NETGEAR X6S (International)
- Max Rotational Speed
- 540°/s
- Max Video Resolution
- FHD: 1080/30fps, HD: 720/30fps
- Max Live View Bitrate
- 6 Mbps
- Maximum Charging Power
- 29 W
- Battery Life On Standby
- 100 minutes
- Initial Launching Speed
- 26 m/s
- Max Launching Frequency
- 10/s
- Operating Frequency [3]
- 2.4 GHz, 5.1 GHz, 5.8 GHz
- Maximum Charging Voltage
- 12.6 V
- Nominal Charging Voltage
- 10.8 V
- Transmission Power (EIRP)
- FCC, SRRC, CE, MIC
- Charging Temperature Range
- 5 to 40 °C (41 to 104 °F)
- Max Still Photo Resolution
- 2560×1440
- Vibration Control Precision
- ±0.02°
- Max Chassis Rotational Speed
- 600°/s
- Controllable Launching Frequency
- 1-8/s
Who uses it
No named customer yet
A customer is listed when a public source names them, or the maker adds them.
Add a customer →Where to buy
Get a price or reach an authorized seller.
No seller listed for your region yet. Ask for a quote.
Are you a distributor? List your company, free.
Every seller is shown equally. Placement is never sold and never affects a score.
Company milestones(estimated)
- Jan 2025LaunchDJI launches Matrice 4 Series
- 2024LaunchInternational launch of Agras T50 and T25
- Apr 2024LaunchDJI announces international launch of Agras T25
- 2023LaunchDJI Inspire 3 officially launched as world's ultimate cinema drone
- Sep 2022LaunchDJI unveils Mavic 3 Enterprise Series with M3E and M3T models
- Aug 2020LaunchRoboMaster EP Core unveiled
- Jun 2019LaunchDJI launches RoboMaster S1
- Oct 2018LaunchPhantom 4 RTK announced in Frankfurt
Compare with
DJI in the news
the maker8 events · last 12 months
- Sep 117,000 Robot Vacuums, One Leaked Token: The DJI Romo Breach Proves Home Agents Have a Single-Point-of-Failure Problem
- Sep 3DJI announces second generation AI-powered ROMO 2 Robot Vaccum with LiDAR guided robot arm
- May 11DJI Romo P2, Romo A2 Robot Vacuum Cleaners Launched With 36,000Pa Suction Power, Self-Cleaning Docking St...
DJI in the news
the maker8 events · last 12 months
News about DJI, the maker, not about this robot specifically, except rows marked this robot. Collected and classified independently across 45 outlets, so a maker cannot add to it. It never changes this robot's RoboScore (the evidence half of the RoboIndex) and it can move it up a board by at most 15 points. See all DJI news
Frequently asked questions
- Who makes the RoboMaster S1?
- The RoboMaster S1 is developed by DJI, based in China.
- What type of robot is the RoboMaster S1?
- The RoboMaster S1 is a Education robot made by DJI.
- How much does the RoboMaster S1 cost?
- The RoboMaster S1 is priced up to US$549.
- When was the RoboMaster S1 launched?
- The RoboMaster S1 was launched in 2019.
