The SF10-C1650 is a Industrial Arm developed by Chaifu Robot (China). Key specifications: arm class small payload, repeatability ±0.05 mm, mounting floor, ceiling, wall, programming teach pendant.
RoboScore
Adequate evidence
No confirmed deployment on record — this score reflects the rest of the record, not verified adoption.
4 of 9 signals present
Recomputed nightly from public data. Missing data is skipped, never zero-filled — and rankings are never for sale.
Weighted factors
average of the 4 scored · blanks don't count
Ranked in the Industrial Arm standing, against 773 robots.
See the standingWill it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
Tell us what your job needs — payload, budget, region, must-have certifications — and we'll show how SF10-C1650 measures up, requirement by requirement. The RoboScore (trust) above is shown for every buyer, regardless.
Overview
The SF10-C1650 is a 10 kg payload, 6‑axis industrial robot from Chai Fu Robot's LOTIC series with a 1651 mm reach. It offers ±0.05 mm repeatability and an IP65 rating, suitable for assembly, machine tending, material handling, and other general manufacturing tasks. Its compact base (384×384 mm) and 196 kg weight enable versatile mounting options.
At a glance
- Built for material handling, machine tending and assembly
- Used across general manufacturing and metal fabrication
- Rated for operation at 0°C to 45°C
Buyer decision signals
Viability
Company established
Availability
Specifications
Category: Industrial Arm- Arm class
- small payload
- Repeatability
- ±0.05 mm
- Mounting
- floor, ceiling, wall
- Programming
- teach pendant
- Industries
- general_manufacturing, metal_fabrication
Company profile
- Founded
- 2011
Detailed specifications
What it is built for4
- Industries
- general manufacturing,metal fabrication
- Applications
- pick and place,assembly,machine tending
- Sub Category
- vertical articulated
- Primary Applications
- material handling,machine tending,assembly
Movement & precision1
- Dof
- 6
Safety & certification3
- Operating Temp
- 0°C to 45°C
- Temperature Range Max C
- 45
- Temperature Range Min C
- 0
Buying & support3
- Price On Request
- true
- Availability Status
- available
- Countries Available
- CN
Other details24
- Base Size Mm
- 384x384
- Body Height Mm
- 1407
- Humidity Max Pct
- 95
- Max Range J1 Deg
- ±165
- Max Range J2 Deg
- +75/-125
- Max Range J3 Deg
- +145/-75
- Max Range J4 Deg
- ±178
- Max Range J5 Deg
- ±125
- Max Range J6 Deg
- ±720
- Max Torque J4 Nm
- 22
- Max Torque J5 Nm
- 22
- Max Torque J6 Nm
- 10
- Max Speed J1 Degs
- 150
- Max Speed J2 Degs
- 160
- Max Speed J3 Degs
- 148
- Max Speed J4 Degs
- 300
- Max Speed J5 Degs
- 300
- Max Speed J6 Degs
- 500
- Vibration Max M S2
- 4.9
- Max Inertia J4 Kgm2
- 1
- Max Inertia J5 Kgm2
- 1
- Max Inertia J6 Kgm2
- 0.2
- Max Joint Speed Deg S
- 500
- Power Consumption Kva
- 2.5
Where to buy
Get a price or reach an authorized seller — pick your region, then request a quote.
No authorized seller is listed for this robot yet — request a quote below and we’ll connect you with Chaifu Robot or an authorized seller.
Request a quote — goes straight to Chaifu Robot.
Every authorized seller serving your region is shown equally — placement is never sold, and this data never affects a robot’s score. A seller’s absence here doesn’t mean they aren’t authorized.
Company milestones
- Nov 2011MilestoneCompany established
- 2020MilestoneSouthern China operation center established
- —MilestoneNorthern China operation center established
Compare with peers
More by Chaifu Robot
Frequently asked questions
- Who makes the SF10-C1650?
- The SF10-C1650 is developed by Chaifu Robot, based in China.
- What type of robot is the SF10-C1650?
- The SF10-C1650 is a Industrial Arm made by Chaifu Robot.
- How much does the SF10-C1650 cost?
- Pricing for the SF10-C1650 is not publicly listed — contact Chaifu Robot for a quote.
- What are the key specifications of the SF10-C1650?
- Key specifications of the SF10-C1650: arm class small payload, repeatability ±0.05 mm, mounting floor, ceiling, wall, programming teach pendant, safety cert. .
