Overview
The VL2500 is a 5 or 6-axis robot from DENSO's high-speed series. It is designed for high-speed industrial applications with pursuit of real high-speed performance. The robot is suitable for various manufacturing and automation tasks requiring advanced speed capabilities and precision control.
Flagship features
- Environmental resistance with IP67 wrist and IP65 main unit
- Built-in field networks (PROFINET, PROFIBUS, DeviceNet) reduce external wiring complexity
- Compatible with 'Palletizing Builder' option in WINCAPS Plus for automated palletizing processes
Specifications
Category: Industrial Arm- Arm class
- standard industrial
- Axes
- 6
- Payload
- ≤ 40 kg
- Reach
- 2503 mm
- Repeatability
- ±0.06 mm
- Weight
- ~655 kg
- IP rating
- IP65
- Mounting
- floor, ceiling, sloping
- Programming
- proprietary app
- Force limiting
- No
- Maturity
- commercial
- Industries
- logistics, general_manufacturing
Detailed specifications
Motion & kinematics1
- Dof
- 4
Safety & certifications1
- Ip Rating Wrist
- IP67
Other17
- Industries
- automotive,electronics,food_beverage,pharmaceutical
- Price Tier
- 40-80K
- Applications
- palletizing,pick_and_place
- Sub Category
- palletizing
- Datasheet Url
- Preview PDF online
- Model Variants
- VLA-4025,VLA-6022
- Company Country
- JP
- Price On Request
- true
- Software Platform
- WINCAPS Plus
- Fieldbus Protocols
- profinet,profibus,devicenet
- Availability Status
- available
- Primary Applications
- palletizing,transportation,inspection,packaging
- Pneumatic Lines Count
- 1
- Additional Information
- - Environmental resistance with IP67 wrist and IP65 main unit. - Built-in field networks (PROFINET, PROFIBUS, DeviceNet) reduce external wiring complexity. - Compatible with 'Palletizing Builder' option in WINCAPS Plus for automated palletizing processes. - Optional accessories include multibus cable, non-adjustable leveling plate, level-adjustable plate kit, protection cover for connector panel, adjustable mechanical stopper kit for 1st axis, and attachment for forklifts.
- Electrical Lines Count
- 14
- Internal Cable Routing
- through_arm
- Offline Programming Software
- WINCAPS Plus
