Overview
The Atex Zone 0 Dredging Robot for Tank Maintenance is designed for closed and semi-closed pools. It has a fully sealed and waterproof design, and the pump station does not need to stop production to cooperate when taking mud underwater.
Detailed specifications
Power & battery2
- Power Consumption W
- 58000
- Power Hydraulic Control Cabin
- The 4-joint combined hydraulic control manifold, with a working pressure of 18Mpa
Sensors1
- Dive Depth
- 10M
Other21
- Auger
- Good impact resistance, length 800mm, full hydraulic drive
- Monitor
- LED high-brightness LCD display, brightness is not less than 800
- Drive Type
- Hydraulic
- Industries
- automotive,metal_fabrication,pharmaceutical,food_beverage,general_manufacturing,other
- Price Tier
- US$80,000.00
- Slurry Pump
- Discharge outlet is 75-100mm, flow rate is 100m³/h, head is 23m, suction particle is 50mm
- Gradeability
- ≤30°
- Travel Speed
- 3-30m/min
- Sub Category
- dredging_robot
- Max Speed M S
- 0.5
- Fuselage Frame
- Made of stainless steel 304
- Price Currency
- USD
- Warranty Years
- 10
- Company Country
- CN
- Procedure Types
- crude oil sludge cleaning,tank maintenance
- Price On Request
- false
- Compatible Vision
- LED high-brightness LCD display, brightness ≥800
- Primary Applications
- other
- Additional Information
- - ATEX Zone 0 rated for explosive environments (crude oil/sludge). - Fully sealed and waterproof design; pump station does not need to stop production during underwater mud extraction. - Dual configuration: floating (for open pools) and box-type (for closed/semi-closed pools; box-type requires openings). - Advanced control: remote control via feedback image from intelligent monitoring system. - High-pressure flushing system (up to 1500 bar) for tough sludge with high sand content. - Hydraulic drive; gradeability ≤30°. - Equipped with automatic balance adjustment for level operation underwater. - Multiple safety features: automatic upgrade safety system, safety alarm devices, and human-computer interaction. - 10-year service life. - Certifications include CE, CB, ETL, RoHS, UR. - Not a traditional industrial-arm robot; it is an underwater cleaning/dredging vehicle.
- Overall Machine Performance
- The size of the whole machine is 1200*900*700mm (with auger device), equipped with slurry suction pump, hydraulic control valve group, and electric control box. Weight less than 300kg.
- Expected Service Life Years
- 10
