TEFUDE TFD-RD4-800A
Built by FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY · China
The TEFUDE TFD-RD4-800A is a Industrial Arm developed by FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY (China). Key specifications: arm class small payload, repeatability ±0.1 mm, tool flange ISO 9409-1, industries food_and_beverage, electronics.
RoboScore
Speculative — thin evidence
No confirmed deployment on record — this score reflects the rest of the record, not verified adoption.
4 of 9 signals present
Recomputed nightly from public data. Missing data is skipped, never zero-filled — and rankings are never for sale.
Weighted factors
average of the 4 scored · blanks don't count
Ranked in the Industrial Arm standing, against 773 robots.
See the standingWill it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
Tell us what your job needs — payload, budget, region, must-have certifications — and we'll show how TEFUDE TFD-RD4-800A measures up, requirement by requirement. The RoboScore (trust) above is shown for every buyer, regardless.
Overview
The TEFUDE TFD-RD4-800A is a 4-axis parallel (delta) robot engineered for high-speed pick-and-place operations in food processing and packaging. It features a 3+1 axis design (X, Y, Z plus rotation), delivering 200 cycles/min with a payload of up to 2.5 kg. The robot's working diameter is 800 mm with a 200 mm effective pick-and-place height. It boasts repeat positioning accuracy of ±0.1 mm and an IP54 ingress protection rating. The stainless steel construction ensures durability in demanding environments, making it suitable for biscuit, bakery, beverage, and snack packaging applications.
At a glance
- Built for material handling and assembly
- Used across food beverage, electronics and general manufacturing
- Rated for operation at 0℃~45℃
- Backed by a 1-year warranty
- Sold in CN and Global
Buyer decision signals
Viability
Patent application filed
Price
purchase
Availability
Specifications
Category: Industrial Arm- Arm class
- small payload
- Repeatability
- ±0.1 mm
- Tool flange
- ISO 9409-1
- Industries
- food_and_beverage, electronics
Company profile
- Founded
- 2012
Detailed specifications
What it is built for5
- Duty Cycle
- continuous 24 7
- Industries
- food beverage,electronics,general manufacturing
- Applications
- pick and place,assembly
- Sub Category
- delta
- Primary Applications
- material handling,assembly
Movement & precision3
- Dof
- 4
- Drive Mode
- Electric
- Control Mode
- Point to Point Control
Safety & certification3
- Operating Temp
- 0℃~45℃
- Temperature Range Max C
- 45
- Temperature Range Min C
- 0
Buying & support10
- Price Tier
- 10-20K
- Pricing Model
- purchase
- Model Variants
- TFD-RD4-600A,TFD-RD4-800A,TFD-RD4-1200A,TFD-RD4-1600A
- Price Currency
- USD
- Warranty Years
- 1
- Lead Time Weeks
- 4
- Price On Request
- false
- Availability Status
- available
- Countries Available
- CN,Global
- Service Network Density
- regional
Other details10
- Material
- 304# Stainless Steel
- Noise Level
- <75 dB
- Installation
- Hoisting
- I/O Interface
- 8in/8out (expandable)
- Operation Mode
- Automatic
- Rotation Angle
- ±360°
- Digital Io Count
- 16
- Relative Humidity
- Rh:20-80%
- Repeat Angle Accuracy
- ±0.2°
- Cycle Time 25 305 25 Sec
- 0.3
Where to buy
Get a price or reach an authorized seller — pick your region, then request a quote.
No authorized seller is listed for this robot yet — request a quote below and we’ll connect you with FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY CO., LTD. or an authorized seller.
Request a quote — goes straight to FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY CO., LTD..
Every authorized seller serving your region is shown equally — placement is never sold, and this data never affects a robot’s score. A seller’s absence here doesn’t mean they aren’t authorized.
Company milestones
- Aug 2012MilestonePatent application filed
- 2012MilestoneCompany established
- —MilestoneHigh-tech enterprise
- —Launch4-axis robotic arm system with 1600 mm working range
- —MilestoneTEFUDE 4-axis robotic arm marketed for food industries
- —LaunchTFD-RD4 four-axis robot product page
- —MilestoneTFD-RD4 product description on TEFUDE site
- —MilestoneTEFUDE company established
Compare with peers
More by FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY
Frequently asked questions
- Who makes the TEFUDE TFD-RD4-800A?
- The TEFUDE TFD-RD4-800A is developed by FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY, based in China.
- What type of robot is the TEFUDE TFD-RD4-800A?
- The TEFUDE TFD-RD4-800A is a Industrial Arm made by FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY.
- How much does the TEFUDE TFD-RD4-800A cost?
- Pricing for the TEFUDE TFD-RD4-800A is not publicly listed — contact FOSHAN TEFUDE AUTOMATION SCIENCE & TECHNOLOGY for a quote.
- What are the key specifications of the TEFUDE TFD-RD4-800A?
- Key specifications of the TEFUDE TFD-RD4-800A: arm class small payload, repeatability ±0.1 mm, tool flange ISO 9409-1, industries food_and_beverage, electronics.
