The AUBO-C3 is a Cobot developed by AUBO Robotics (China). Key specifications: axes 6, payload 3 kg, reach 625 mm, repeatability ±0.05 mm.
Robo Index
Adequate evidence
4 of 10 signals present
Recomputed nightly from public data. Missing data is skipped, never zero-filled — and rankings are never for sale.
Weighted factors
average of the 4 scored · blanks don't count
Will it fit your job?
Tell us the job in plain words — we'll show how this robot measures up, line by line.
Tell us what your job needs — payload, budget, region, must-have certifications — and we'll show how AUBO-C3 measures up, requirement by requirement. The Robo Index (trust) above is shown for every buyer, regardless.
Overview
遨博最小自重的协作机器人，自重仅16kg，负载3kg，臂展782mm，最大工作半径625mm，巧轻便，占地面积小。
Flagship features
- **最小自重协作机器人**: 自重仅16kg，极轻便。
- **开放生态系统**: SDK支持多语言（C/C++/C#/Lua/Python/JavaScript/Java）及Windows+Linux系统。
- **ROS兼容**: 明确支持ROS/ROS2系统。
- **教育案例**: 有颜色分拣、字符拼接、打磨实训平台等教育应用案例。
- **关节运动参数详细**: 提供各关节运动范围（±175°至±360°）和最大速度（185°/s）。
- **防护等级**: 本体IP54，控制柜IP30，示教器IP54。
Buyer decision signals
Viability
AUBO Robotics at SIMTOS 2024 in Seoul
Availability
Specifications
Category: Cobot- Axes
- 6
- Payload
- 3 kg
- Reach
- 625 mm
- Repeatability
- ±0.05 mm
- Weight
- 16 kg
- TCP speed
- 1.9 m/s
- IP rating
- IP54
- API / SDK
- Yes
Company profile
- Founded
- 2015
Detailed specifications
Motion & kinematics12
- Joint 1 Range Deg
- 360
- Joint 2 Range Deg
- 175
- Joint 3 Range Deg
- 156
- Joint 4 Range Deg
- 175
- Joint 5 Range Deg
- 175
- Joint 6 Range Deg
- 360
- Joint 1 Speed Degs
- 185
- Joint 2 Speed Degs
- 185
- Joint 3 Speed Degs
- 185
- Joint 4 Speed Degs
- 185
- Joint 5 Speed Degs
- 185
- Joint 6 Speed Degs
- 185
Power & battery5
- Peak Power W
- 600
- Power Supply
- 100-240VAC, 50-60Hz
- Average Power W
- 150
- Io Power Output Voltage Tool Tip
- 0V/12V/24V
- Io Power Output Current Tool Tip A
- 0.8
Compute1
- Ros Compatible
- true
Safety & certifications4
- Teach Pendant Ip Rating
- IP43
- Control Cabinet Ip Rating
- IP43
- Digital Safety Inputs Control
- 16
- Digital Safety Outputs Control
- 16
Other31
- Sdk Support
- C/C++/C#/Lua/Python
- Applications
- pick_and_place,visual_inspection,polishing,grinding,sorting
- Sub Category
- 6-axis cobot
- Cable Length M
- 5
- Mounting Angle
- 任意角度
- Operating Temp
- 0-40
- Company Country
- CN
- Ambient Humidity
- 90%相对湿度（非冷凝）
- Deployment Notes
- 教育视觉案例：字符拼接、颜色分拣；打磨案例；教育实训平台案例。
- Industries Served
- education,electronics,automotive,metalwork,food_bev,pharma,logistics
- Cable Max Length M
- 8
- Availability Status
- available
- Digital Io Tool Tip
- 4
- Teach Pendant Color
- 黑色+白色
- Teach Pendant Model
- AUBO-TP-E
- Mounting Diameter Mm
- 140
- Analog Inputs Control
- 4
- Control Cabinet Model
- AUBO-CB-M
- Programming Interface
- code_python,code_ros
- Additional Information
- - **最小自重协作机器人**: 自重仅16kg，极轻便。 - **开放生态系统**: SDK支持多语言（C/C++/C#/Lua/Python/JavaScript/Java）及Windows+Linux系统。 - **ROS兼容**: 明确支持ROS/ROS2系统。 - **教育案例**: 有颜色分拣、字符拼接、打磨实训平台等教育应用案例。 - **关节运动参数详细**: 提供各关节运动范围（±175°至±360°）和最大速度（185°/s）。 - **防护等级**: 本体IP54，控制柜IP30，示教器IP54。 - **供电电源**: 100-240VAC宽压输入，50-60Hz。 - **I/O丰富**: 控制柜具有12个数字输入（6安全）、12个数字输出（6安全），末端工具端提供可配置电源（0V/12V/24V，0.8A）。 - **通讯协议**: 支持Ethernet/IP、ModBus-RTU/TCP、Profinet。 - **控制柜尺寸**: 340mm*260mm*100mm，重量7.5kg。 - **连接线缆**: 可定制最长8m。 - **无标注价格/价格层级**: 页面未提及价格，买家需联系销售人员。
- Analog Inputs Tool Tip
- 2
- Analog Outputs Control
- 4
- Control Cabinet Whd Mm
- 390 x 370 x 265
- Digital Inputs Control
- 16
- Communication Protocols
- Ethernet, ModBus-RTU/TCP, Profinet(选配)
- Digital Outputs Control
- 16
- Teach Pendant Weight Kg
- 1.57
- Digital Outputs Tool Tip
- 4
- Control Cabinet Weight Kg
- 15
- Teach Pendant Dimensions Mm
- 355 x 235 x 54
- Teach Pendant Cable Length M
- 4
Where to buy
Get a price or reach an authorized seller — pick your region, then request a quote.
No authorized seller is listed for this robot yet — request a quote below and we’ll connect you with AUBO Robotics or an authorized seller.
Request a quote — goes straight to AUBO Robotics.
Every authorized seller serving your region is shown equally — placement is never sold, and this data never affects a robot’s score. A seller’s absence here doesn’t mean they aren’t authorized.
Company milestones
- Apr 2024MilestoneAUBO Robotics at SIMTOS 2024 in Seoul
- Jul 2023MilestoneAUBO-i5 & CB-M user manual published
- Jul 2023MilestoneAUBO-i3 user manual updated
- Apr 2019DeploymentAUBO at AUTOMATE 2019
- 2026MilestoneAnnual production milestone
- 2025MilestoneAUBO Robotics corporate profile states company founded in 2015
- 2019MilestoneAUBO-i7 listed in product line at Automate 2019
- 2015MilestoneCompany founded
Compare with peers
Frequently asked questions
- Who makes the AUBO-C3?
- The AUBO-C3 is developed by AUBO Robotics, based in China.
- What type of robot is the AUBO-C3?
- The AUBO-C3 is a Cobot made by AUBO Robotics.
- How much does the AUBO-C3 cost?
- Pricing for the AUBO-C3 is not publicly listed — contact AUBO Robotics for a quote.
- What are the key specifications of the AUBO-C3?
- Key specifications of the AUBO-C3: axes 6, payload 3 kg, reach 625 mm, repeatability ±0.05 mm, weight 16 kg.
